Lift |
Spacing 15.24 mm
AKZ710/..-15.24-V-GREEN
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
0.2 mm²
4.0 mm²
0.2mm²
2.5 mm²
0.25 mm²
2.5 mm²
Order Data (Spacing 15.24 mm)
Insulating Material
Material
Flammability Class
PA 6.6
2
23.46
38.70
53.94
69.18
84.42
AKZ710/2-15.24-V-GREEN
AKZ710/3-15.24-V-GREEN
AKZ710/4-15.24-V-GREEN
AKZ710/5-15.24-V-GREEN
AKZ710/6-15.24-V-GREEN
Poles
Width (mm)
Article Designation
Article
Number
50710020253 E
50710030253 E
50710040253 D
50710050253 D
50710060253 D
PU
100
100
50
50
50
UL 94 V-0
3
4
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
5
6
Dimensions
Stripped Length
PCB Hole Diameter
8.0 mm
1.3 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
260 °C
3-4 s
Accessoires
Figure
Designation
Bridge, 2-pole, insulated,
BRI/2-7.5/7.62-L8.2-LIGHT GREY
Article Number
Order Data:
50000000017
Materials
Clamp
Screw
Solder Tab
Brass
Steel
Copper
Alloy
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
-
Screw Cover SC-AK700-YELLOW
Order Data:
50700000004
Colours
BLACK, RAL 9011
PEBBLE GREY, RAL 7032
GREEN, RAL 6018
BLUE, RAL 5015
LIGHT GREEN, similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions. Special
colours on request.
Ratings
UseGroup
Rated Voltage
Rated Current
Rated Wire Size
- solid
- stranded
Torque
Screw Size
Test Voltage
B
600 V
20 A
C
600 V
20 A
D
-
-
min
1000 V
24 A
max
4.0 mm²
2.5 mm²
0.50 Nm
M3
3.5 kV
AWG 22-12
AWG 22-12
0.45 Nm
M3
2.20 kV
AWG 22-12
AWG 22-12
0.45 Nm
M3
2.20 kV
-
-
-
-
-
0.5 mm²
0.5 mm²
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
