Lift |
Spacing 3.81 mm
AKZ1710/..-3.81-GREEN
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.14 mm²
1.5 mm²
0.14 mm²
1.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
-
-
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
7.62
11.43
15.24
19.05
22.86
26.67
30.48
34.29
38.10
41.91
45.72
49.53
53.34
57.15
60.96
64.77
68.58
72.39
76.20
Article Designation
AKZ1710/2-3.81-GREEN
AKZ1710/3-3.81-GREEN
AKZ1710/4-3.81-GREEN
AKZ1710/5-3.81-GREEN
AKZ1710/6-3.81-GREEN
AKZ1710/7-3.81-GREEN
AKZ1710/8-3.81-GREEN
AKZ1710/9-3.81-GREEN
AKZ1710/10-3.81-GREEN
AKZ1710/11-3.81-GREEN
AKZ1710/12-3.81-GREEN
AKZ1710/13-3.81-GREEN
AKZ1710/14-3.81-GREEN
AKZ1710/15-3.81-GREEN
AKZ1710/16-3.81-GREEN
AKZ1710/17-3.81-GREEN
AKZ1710/18-3.81-GREEN
AKZ1710/19-3.81-GREEN
AKZ1710/20-3.81-GREEN
Article Number
51710020021F
51710030021F
51710040021F
51710050021F
51710060021E
51710070021E
51710080021D
51710090021D
51710100021D
51710110021D
51710120021D
51710130021D
51710140021D
51710150021D
51710160021D
51710170021D
51710180021D
51710190021D
51710200021D
PU
200
200
200
200
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule 0.25 mm²
min
Stranded with Ferrule 1.0 mm²
max
Dimensions
Stripped Length
Materials
Clamp
Screw
Contact Spring
Brass
Bronze
Bronze
7.0 mm
Colours
GREEN
LIGHT GREY
LIGHT GREEN
RAL6018
RAL7035
similar RAL 6018
RAL6018
RAL7035
Accessories
Figure
Designation
Bridge, 2-pole, BR/2-5.0/5.08-L7.5
Article Number
50000000015
similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Counterparts (Spacing 3.81 mm)
Pin Strip/Terminal Blocks
STLZ1550
STLZ1590
STLZ1570
Bridge, 3-pole, BR/3-3.5/3.81-L7.5
50000000016
Bridge, 2-pole, insulated, BRI/2-7.0/7.62-
L7.5-LIGHT GREY
50000000018
Ratings
Usegroup
Rated Voltage
Rated Current
Overvoltage Category
Rated Wire Size
solid
stranded
Torque
Screw Size
Test Voltage
Pollution Degree
B
300 V
8A
C
-
-
D
300 V
8A
min
0.5 mm² (6 A)
0.5 mm² (6 A)
160 V
9A
III
max
1.5 mm² (9 A)
1.5 mm² (9 A)
0.25 Nm
M2
2.5 kV
3
AWG 28-16
AWG 28-16
0.25 Nm
M2
1.6 kV
-
-
-
-
-
AWG 28-16
AWG 28-16
0.25 Nm
M2
1.6 kV
