Push-In |
Spacing 5.0 mm
AK4200/..-5.0-H-BAGY
- 1- to n-poles
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
0.2 mm²
4.0 mm²
0.2mm²
2.5 mm²
0.2 mm²
2.5 mm²
Order Data (Spacing 5.0 mm)
Insulating Material
Material
Flammability Class
PA 6.6
1
6.40
11.40
16.40
21.40
26.40
31.40
36.40
41.40
46.40
51.40
56.40
61.40
AK4200/1-5.0-H-baGY
AK4200/2-5.0-H-baGY
AK4200/3-5.0-H-baGY
AK4200/4-5.0-H-baGY
AK4200/5-5.0-H-baGY
AK4200/6-5.0-H-baGY
AK4200/7-5.0-H-baGY
AK4200/8-5.0-H-baGY
AK4200/9-5.0-H-baGY
AK4200/10-5.0-H-baGY
AK4200/11-5.0-H-baGY
AK4200/12-5.0-H-baGY
Poles
Width (mm)
Article Designation
Article
Number
54200010451 E
54200020451 D
54200030451 D
54200040451 D
54200050451 D
54200060451 D
54200070451 D
54200080451 D
54200090451 D
54200100451 D
54200110451 D
54200120451 D
PU
100
50
50
50
50
50
50
50
50
50
50
50
UL 94 V-0
2
3
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
4
5
6
Dimensions
Stripped Length
PCB Hole Diameter
10.0 mm
1.1 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
260 °C
3-4 s
7
8
9
10
11
Materials
Solder Tab
Clamp Spring
Copper
Alloy
Stainless
Steel
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
-
12
Accessoires
Figure
Designation
Spacer SPC-AK4200-baGY
Article Number
Order Data:
54200000000
Colours
BASALT GREY, RAL 7012
TRAFFIC GREY, RAL 7042
LIGHT GREY, RAL 7035
BLACK, RAL 9011
LIGHT GREEN, similar RAL 6018
GREEN, RAL 6018
GREEN/YELLOW, RAL 6018 - 1018/S
RED, RAL 3003
ORANGE, RAL 2011
BLUE, RAL 5015
WHITE, RAL 9003
Colours according to RAL, there may be variations on colour due to production conditions. Special
colours on request.
Side Wall with Coding Pin
SW-AK4200-CP-H-baGY
Order Data:
54200000002
Ratings
UseGroup
Rated Voltage
Rated Current
Overvoltage Category
Rated Wire Size
- solid
- stranded
Test Voltage
B
300 V
20 A
C
-
-
D
300 V
10 A
250 V
24 A
III
min
max
2.5 mm²
2.5 mm²
2.0 kV
AWG 24-12
AWG 24-12
1.60 kV
-
-
-
AWG 24-12
AWG 24-12
1.60 kV
0.2 mm²
0.2 mm²
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
