Push-In |
Spacing 3.5 mm
AK4541/..FRKD-3.5-BASALTGREY
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
0.2 mm²
1.5 mm²
0.2mm²
1.5 mm²
0.25 mm²
1.5 mm²
Order Data (Spacing 3.5 mm)
Insulating Material
Material
Flammability Class
PA 6.6
2
16.80
20.30
23.80
27.30
30.80
34.30
37.80
41.30
44.80
48.30
51.80
55.30
58.80
62.30
65.80
69.30
72.80
76.30
79.80
AK4541/2FRKD-3.5-BASALTGREY
AK4541/3FRKD-3.5-BASALTGREY
AK4541/4FRKD-3.5-BASALTGREY
AK4541/5FRKD-3.5-BASALTGREY
AK4541/6FRKD-3.5-BASALTGREY
AK4541/7FRKD-3.5-BASALTGREY
AK4541/8FRKD-3.5-BASALTGREY
AK4541/9FRKD-3.5-BASALTGREY
AK4541/10FRKD-3.5-BASALTGREY
AK4541/11FRKD-3.5-BASALTGREY
AK4541/12FRKD-3.5-BASALTGREY
AK4541/13FRKD-3.5-BASALTGREY
AK4541/14FRKD-3.5-BASALTGREY
AK4541/15FRKD-3.5-BASALTGREY
AK4541/16FRKD-3.5-BASALTGREY
AK4541/17FRKD-3.5-BASALTGREY
AK4541/18FRKD-3.5-BASALTGREY
AK4541/19FRKD-3.5-BASALTGREY
AK4541/20FRKD-3.5-BASALTGREY
Poles
Width (mm)
Article Designation
Article
Number
54541036401 F
54541046401 F
54541056401 E
54541066401 E
PU
54541026401 G 250
200
200
100
100
UL 94 V-0
3
4
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
5
6
7
54541076401 D 50
54541086401 D 50
54541096401 D 50
54541106401 D 50
54541116401 D 50
54541126401 D 50
54541136401 D 50
54541146401 D 50
54541156401 D 50
54541166401 D 50
54541176401 D 50
54541186401 D 50
54541196401 D 50
54541206401 D 50
Dimensions
Stripped Length
10.0 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
-
8
9
10
11
12
Materials
Contact Spring
Clamp Spring
tin plated
Stainless
Steel
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
-
13
14
15
16
17
18
Colours
BASALT GREY, RAL 7012
GREEN, RAL 6018
LIGHT GREEN, similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions. Special
colours on request.
19
20
Accessoires
Figure
Designation
Series AK4541 with pull relief
Article Number
Order Data: on request
Counterparts (Spacing 3.5 mm)
Pin Strip
STLZ1541
Ratings
UseGroup
Rated Voltage
Rated Current
Overvoltage Category
Rated Wire Size
- solid
- stranded
Test Voltage
Pollution Degree
B
150 V
8A
C
50 V
8A
D
150 V
8A
320 V
8A
II
min
max
1.5 mm²
1.5 mm²
2.5 kV
2
* Approval Pending
AWG 24-16
AWG 24-16
1.30 kV
AWG 24-16
AWG 24-16
1.10 kV
AWG 24-16
AWG 24-16
1.30 kV
0.2 mm²
0.2 mm²
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
