SHEET 1 OF 1
12.70
[.500 in]
3
2
5.08
[.200 in]
1
1.85
[.073 in]
6.86
[.270 in]
12.70
[.500 in]
2
KEYWAY
.71
[.028 in]
5.08
[.200 in]
1.22
[.048 in]
1.02
[.040 in]
4.70
[.185 in]
RECOMMENDED P.C.B. MOUNTING
SWITCH FUNCTION
POS. 1
POS. 2
POS. 3
ON
2-3
OFF
OPEN
ON
2-1
1
3
POS. 1
25
POS. 2
POS. 3
CIRCUIT: SPDT
10.41
[.410 in]
1/4-40 UNS THREAD
8.40
[.331 in]
E-SWITCH
MARKING ON
OPPOSITE SIDE
.50
[.020 in]
8.65
[.341 in]
NOTE:
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X= 0.4
X.XX= 0.25
3. TERMINAL NUMBERS FOR REF ONLY
4. CONTACT MATERIAL: GOLD
5. RATING: 0.4 (VA) Max. @ 20V (AC or DC)
6. ELECTRIC LIFE: 40,000 MAKE-AND-BREAK CYCLES
AT FULL LOAD.
7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.
8. DIELECTRIC STRENGTH: 1,000 V RMS @ SEA LEVEL.
9. OPERATING TEMP.: -30 C to 85 C
10.
DENOTES CRITICAL PARAMETER.
11. 2011/65/EU (ROHS) COMPLIANT
8.89
[.350 in]
12.70
[.500 in]
3
1
4.70
[.185 in]
2
3
.76
[.030 in]
3.17
[.125 in]
1.27
[.050 in]
A
REV
23225
PCR NO
NEW RELEASE
DESCRIPTION
3/8/18
DATE
MJR
BY
TITLE
SCALE
100SP3T1B1M6RE
DATE
DR
DWG
REV
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
2:1
3/8/2018
MJR
T113085
A
