Thru-Hole Power Inductor
ELECTRONICS INC.
EPI AVM3 Series
• Low loss material ensures operation in high frequency switching
converters, such as Buck, Boost or as output averaging filter inductor
• Also suitable for use in high quality filter applications
• UL 1446 Class B Insulation System
• UL 94V-0 Recognized Material
• In Header Mount Package
• Low Cost Inductor
Primary Specification
Part
Number
EPI100133AVM3
EPI200143AVM3
EPI200932AVM3
EPI220153AVM3
EPI470153AVM3
EPI500942AVM3
EPI500103AVM3
EPI101752AVM3
EPI101802AVM3
EPI101432AVM3
EPI151752AVM3
EPI251422AVM3
EPI471202AVM3
EPI501192AVM3
EPI681102AVM3
EPI751342AVM3
EPI751242AVM3
EPI102212AVM3
EPI102102AVM3
Induct.
(µH ± 20%)
@ 0 Adc
10.04
20.96
21.25
21.38
45.98
49.60
52.27
97.22
95.32
101.68
150.58
251.10
478.90
504.97
686.38
749.33
754.42
1004.40
1027.52
Induct.
(µH ± 15%)
@ I Sat
7
14.6
14.8
13.6
23.3
34.6
36.4
65
48
71
105
175
374
352
613
522
526
700
880
DCR
(Ω Typ.)
Idc
(A)
I Sat
(A)
Core Loss
(mW)
@ Vt
11.4
13.5
77
.006
11.4
14.5
106
.009
7.8
9.3
77
.011
15
15
107
.009
15
15
107
.010
7.6
9.4
106
.017
10.5
10.2
134
.015
8.2
7.5
134
.024
8.0
8.0
171
.030
4.4
4.3
77
.038
7.7
7.5
171
.030
4.2
4.2
106
.077
2.0
2.0
107
.268
1.7
1.9
77
.267
1.0
1.0
107
.662
3.4
3.4
171
.169
1.8
2.4
106
.341
1.5
2.1
106
.510
1.0
1.0
107
.810
• Switching Frequency :
Up to 500 KHz
•
Vt
(V-µSec.)
@ 100 KHz
11.0
19.0
16.0
19.2
28.1
29.5
33.5
45.7
42.0
35.0
66.0
66.0
91.0
77.9
109
147.3
114.3
131.9
133
Energy
(µJ)
@ I Sat
638
1535
640
1531
2621
1527
1894
1823
1544
655
2951
1543
747
635
307
3017
1514
1543
440
Temp.
Rise
@ Idc (°C)
21
20
19
34
38
18
23
26
34
20
18
22
21
21
15
19
19
20
17
Schematic
A
A
A
B
B
A
A
A
B
A
A
A
B
A
B
A
A
A
B
Package AVM3
1.350 Max.
(34.29)
Schematic A
1
3
1.360
Max.
(34.54)
Schematic B
1
.054 Ø Max.
(1.37 Ø)
.200 ± .020
(5.08 ± .500)
Marking:
PCA
EPIXXXXXXAVM3
D.C.
.057 Ø Max.
(1.45 Ø)
.600
(15.24)
1
2
3
8.25
Max.
(20.96)
4
.900
(22.86)
2
.600
(15.24)
1
Bottom
View
.900
(22.86)
Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25
PCA ELECTRONICS, INC.
16799 SCHOENBORN ST.
NORTH HILLS, CA 91343
Product performance is limited to specified parameters. Data is subject to change without prior notice.
CSIXXXXXXAVM3 Rev. 1
9/22/03 FT
TEL: (818) 892-0761
FAX: (818) 894-5791
http://www.pca.com
