1N5304 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> 1N5304

1N5304: DescriptionCurrent Regulator Diode, 1.8mA I(S), 1.75V V(L), Silicon,; CategoryDiscrete semiconductor diode; File Size36KB，1 Pages; ManufacturerAeroflex; Websitehttp://www.aeroflex.com/

Download Datasheet Parametric Compare View All

1N5304 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	1N5304	-	-	View	Buy Now

1N5304 Overview

Current Regulator Diode, 1.8mA I(S), 1.75V V(L), Silicon,

1N5304 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Aeroflex
Parts packaging code	DO-7
package instruction	O-LALF-W2
Contacts	2
Reach Compliance Code	unknown
ECCN code	EAR99
Is Samacsys	N
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	CURRENT REGULATOR DIODE
Minimum dynamic impedance	420000 Ω
JEDEC-95 code	DO-7
JESD-30 code	O-LALF-W2
JESD-609 code	e0
Maximum knee impedance	74000 Ω
Maximum limit voltage	1.75 V
Number of components	1
Number of terminals	2
Maximum operating temperature	175 °C
Minimum operating temperature	-55 °C
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum power dissipation	0.5 W
Certification status	Not Qualified
Guideline	MIL-19500/463
Nominal regulation current (Ireg)	1.8 mA
Maximum repetitive peak reverse voltage	100 V
surface mount	NO
technology	FIELD EFFECT
Terminal surface	TIN LEAD
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

CURRENT LIMITER

FIELD EFFECT DIODES

1N5283 - 1N5314

PART

NUMBER

♦

1N5283

♦

1N5284

♦

1N5285

♦

1N5286

♦

1N5287

♦

1N5288

♦

1N5289

♦

1N5290

♦

1N5291

♦

1N5292

♦

1N5293

♦

1N5294

♦

1N5295

♦

1N5296

♦

1N5297

♦

1N5298

♦

1N5299

♦

1N5300

♦

1N5301

♦

1N5302

♦

1N5303

♦

1N5304

♦

1N5305

♦

1N5306

♦

1N5307

♦

1N5308

♦

1N5309

♦

1N5310

♦

1N5311

♦

1N5312

♦

1N5313

♦

1N5314

REGULATOR

CURRENT

Ip (mA) @ Vs = 25V

NOM

MIN

MAX

0.22

0.24

0.27

0.30

0.33

0.39

0.43

0.47

0.56

0.62

0.68

0.75

0.82

0.91

1.00

1.10

1.20

1.30

1.40

1.50

1.60

1.80

2.00

2.20

2.40

2.70

3.00

3.30

3.60

3.90

4.30

4.70

0.198

0.216

0.243

0.270

0.297

0.351

0.387

0.423

0.504

0.558

0.612

0.675

0.738

0.819

0.900

0.990

1.080

1.170

1.260

1.350

1.440

1.620

1.800

1.980

2.160

2.430

2.700

2.970

3.240

3.510

3.870

4.230

0.242

0.264

0.297

0.330

0.363

0.429

0.473

0.517

0.616

0.682

0.748

0.825

0.902

1.001

1.100

1.210

1.320

1.430

1.540

1.650

1.760

1.980

2.200

2.420

2.640

2.970

3.300

3.630

3.960

4.290

4.730

5.170

MIN REGULATOR

IMPEDANCE

Zs @ Vs = 25 V

(M OHM)

25.00

19.00

14.00

9.00

6.60

4.10

3.30

2.70

1.90

1.55

1.35

1.15

1.00

0.88

0.80

0.70

0.640

0.580

0.540

0.510

0.475

0.420

0.395

0.370

0.345

0.320

0.300

0.280

0.265

0.255

0.245

0.235

DO-7

500 mW

100 V

-55 to + 175°C

-55 to + 175° C

MIN KNEE

IMPEDANCE

Zk @ Vk = 6V

(M OHM )

2.750

2.350

1.950

1.600

1.350

1.000

0.870

0.750

0.560

0.470

0.400

0.335

0.290

0.240

0.205

0.180

0.155

0.135

0.115

0.105

0.092

0.074

0.061

0.052

0.044

0.035

0.029

0.024

0.020

0.017

0.014

0.012

MAX LIMITING

VOLTAGE

@ I

= 0.8 Ip

(VOLTS)

1.00

1.05

1.10

1.13

1.15

1.20

1.25

1.29

1.35

1.40

1.45

1.50

1.55

1.60

1.65

1.75

1.85

1.95

2.00

2.15

2.25

2.35

2.50

2.60

2.75

2.90

Package Style

DC Power Dissipation

Peak Operating Voltage

Operating Temperature (Topr)

Storage Temperature (Tstg)

♦

Available in JAN, JANTX and JANTXV

HIGHER REGULATOR CURRENT TYPES AVAILABLE (>5.17 mA)

P.O. BOX 609

•

ROCKPORT, MAINE 04856

•

207-236-6076

•

FAX 207-236-9558

-23-
