2,54
0,9
1,5
a1
Verpackt in Tray
- tray packaging
Verpackungseinheit 182 Stück
- packaging unit 182
max. 342
3
1,8
0,6
Abdeckung vorverrastet
Abdeckung verpresst
cover loose mounted
5,55
cover pressed on
5
6 x 14 = 84
14
X
max. 128
11,54
15
6,6
Einzelheit X
7,74
4,55
4
detail X
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
Information:
Codierung grün -
coding green
Tolerances
All Dimensions
in mm
Scale
3:1
All rights reserved.
Only for Information.
To ensure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
b
Index
25.02.2014
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
F 2,54 SRC-A, 2-polig
www.ERNI.com
Class
100302070001
SRCBUG
K
A3
