Band-in-a-Can Backshell with Strain-Relief Clamp
and Self-Locking Rotatable Coupling
CONNECTOR DESIGNATOR:
Angle and Profile
S
- Straight
W
- 90° Elbow
Product Series
447
- EMI/RFI Non-Environmental
Banding Backshells
Basic Part
Number
Band Option
Band supplied
with
K
option
(Omit
for none)
447-329
Composite EMI/RFI Environmental
Composite
Backshells
Finish Symbol
(See
Table III)
A
A
F
L
H
G
U
MIL-DTL-5015, -26482 Series II, and
-83723 Series I and III
MIL-DTL-38999 Series I, II
MIL-DTL-38999 Series 1.5 (JN1003)
MIL-DTL-38999 Series III and IV
MIL-DTL-28840
DG123 and DG123A
Cable Entry
(See
Table IV)
447
H
S
329
XM
19 20
C
K
S
B
SELF-LOCKING
ROTATABLE COUPLING
STANDARD PROFILE
Connector Designator
A, F, L, H, G and U
Connector Shell Size
(See
Table II)
Strain Relief
Style
C
- Clamp
N
- Nut
Slot Option
S
- Pigtail
Termin. Slot
(Omit
for none)
C
Accommodates 600-052-1 Band
O-ring
1.60 (40.6) Max.
.44 (11.2)
Typ.
1.38 (35.1) Max.
O-ring
Cable
Range H
D
Anti-Decoupling
Device
Pigtail
Termination
Slot
Entry
Dia.
Clamp
E
NOTES
1.
Metric dimensions (mm) are in
parenthesis and are for reference only.
Coupling nut supplied unplated.
See Table I in Intro for front-end
dimensional details.
Entry
Diameter
Nut
E
F
G
Accommodates
600-052-1
Band
F
2.
3.
1.38 (35.1) Max.
Cable
Range
G
J
© 2009 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
A-80
Band-in-a-Can Backshell with Strain-Relief Clamp
and Self-Locking Rotatable Coupling
TABLE II: CONNECTOR SHELL SIZE
Shell Size For
Connector Designator*
A F/L H G U ± .06
08 08 09 – –
.69
10 10 11 – 08
.75
12 12 13 11 10
.81
14 14 15 13 12
.88
16 16 17 15 14
.94
18 18 19 17 16
.97
20 20 21 19 18 1.06
22 22 23 – 20 1.13
24 24 25 23 22 1.19
28 – – 25 24 1.34
E
F
G
Max Entry
Dash No.**
10
12
14
16
20
20
22
24
28
32
(1.5)
(17.5)
(19.1)
(20.6)
(22.4)
(23.9)
(24.6)
(26.9)
(28.7)
(30.2)
(34.0)
± .09
.88
1.00
1.13
1.31
1.38
1.44
1.63
1.75
1.88
2.13
(2.3) ± .09
(22.4) 1.19
(25.4) 1.25
(28.7) 1.31
(33.3) 1.38
(35.1) 1.44
(36.6) 1.47
(41.4) 1.56
(44.5) 1.63
(47.8) 1.69
(54.1) 1.78
(2.3)
(30.2)
(31.8)
(33.3)
(35.1)
(36.6)
(37.3)
(39.6)
(41.4)
(42.9)
(45.2)
**Consult factory for additional entry sizes available.
TABLE III: FINISH
Symbol
XM
XMT
XW
Finish Description
2000 Hour Corrosion Resistant Electroless Nickel
2000 Hour Corrosion Resistant Ni-PTFE, Nickel-
Fluorocarbon Polymer.
1000 Hour Grey
TM
2000 Hour Corrosion Resistant Cadmium/Olive Drab
over Electroless Nickel
Entry
Code
10
12
14
16
18
20
22
24
28
32
*
**
TABLE IV: CABLE ENTRY
Cable Range **
Entry Dia.*
H
J
±.06 (1.5) ±.06 (1.5) ±.03 (0.8) Minimum Maximum
.94 (23.9)
.80 (20.3) .22 (5.6)
.13 (3.3) .25 (6.4)
.25 (6.4) .38 (9.7)
1.17 (29.7)
.93 (23.6) .28 (7.1)
1.28 (32.5) 1.06 (26.9) .34 (8.6)
.31 (7.9) .44 (11.2)
1.41 (35.8) 1.22 (31.0) .46 (11.7)
.50 (12.7) .63 (15.9)
.56 (14.2) .69 (17.5)
1.50 (38.1) 1.24 (31.5) .55 (14.0)
.63 (16.0) .75 (19.1)
1.56 (39.6) 1.37 (34.8) .62 (15.7)
1.69 (42.9) 1.49 (37.8) .70 (17.8)
.75 (19.1) .88 (22.2)
.88 (22.4) 1.00 (25.4)
1.81 (46.0) 1.62 (41.1) .78 (19.8)
1.91 (48.5) 1.68 (42.7) .85 (21.6) 1.00 (25.4) 1.13 (28.6)
2.02 (51.3) 1.82 (46.2) .95 (24.1) 1.13 (28.6) 1.25 (31.8)
Entry diameter equals maximum wire bundle diameter.
Cable range equals diameter of cable outer jacket.
© 2009 Glenair, Inc.
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
A-81
Composite
Backshells
447-329
Composite EMI/RFI Environmental
A
B
C
D
E
F
G
