EPE6279S: DescriptionQuad Interface Filter Module; CategoryPower management transformer; File Size227KB，1 Pages; ManufacturerPCA Electronics Inc.; Websitehttp://www.pca.com/

Download Datasheet Parametric View All

EPE6279S Overview

Quad Interface Filter Module

EPE6279S Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Reach Compliance Code	compli
ECCN code	EAR99
Is Samacsys	N
Other features	HEIGHT DIMENSION INCLUDES TERMINAL ALSO; OPTIMIZED FOR USE WITH LEVEL ONE LXT901/944 AND QUAD PH
application	10 BASE-T
high	5.46 mm
Insulation voltage	1500 V
JESD-609 code	e0
length	28.45 mm
Manufacturer's serial number	EPE6279S
Installation features	SURFACE MOUNT
Number of functions	4
physical size	28.45mm X 12.19mm X 5.46mm
Primary inductance	200 µH
surface mount	YES
Terminal surface	Tin/Lead (Sn/Pb)
Transformer type	DATACOM TRANSFORMER
Turns ratio (Np:Ns)	1CT:1.414CT; 1:1
width	12.19 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Quad Interface Filter Module

ELECTRONICS INC.

EPE6279S

• Optimized for Level One LXT901/944 and Quad PH (TNETE 2004)

• Complies with or exceeds IEEE 802.3, 10Base-T Standards

Electrical Parameters @ 25° C

Inductance

(µH Min.)

@ 100 KHz,

0.1 Vrms

Cable Side

200

Interwinding

Capacitance

(pF Max.)

@ 100 KHz,

0.1 Vrms

Xmit/Rcv

12/12

Leakage

Inductanc

e(µH

Max.)

@ 100 KHz,

0.1 Vrms

Xmit/Rcv

0.3/0.3

@ 10

MHz

Xmit

-40

@ 50

MHz

Xmit

-30

CMRR

(dB Min.)

[Xmit]

@ 100

MHz

Xmit

-15

@ 200

MHz

Xmit

-10

Return Loss

(dB Min.)

5-10 MHz

@ 100Ω

Xmit/Rcv

-20/-20

5-10 MHz

@ 85Ω, 115Ω

Xmit/Rcv

-15/-15

1500

-45

Hipot

(Vrms)

Crosstalk

(dB Min.)

5-10

MHz

Schematic

Receive Channels

1

2

9

10

1:1

40

39

32

31

11

12

19

20

1:1

30

29

22

21

3

5

4

7

6

8

1CT : 2 CT

Transmit Channels

1CT : 2 CT

38

36

37

34

35

33

13

15

14

17

16

18

1CT : 2 CT

28

26

27

24

25

23

Package

1.120

(28.45)

.090

(2.29)

PCA

EPE6279S

Date Code

40

.480

(12.19)

.670

(17.02)

.050

(1.27)

21

Solder Pad Layout

1

20

.030

(.762)

.008/.020

(.203/.508)

0°-8°

.008/.012

(.203/.305)

.090

(2.29)

.950

(24.13)

.215

(5.46)

.035

(.889)

.050

(1.27)

.016/.022

(.406/.559)

.630

(16.00)

Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25

PCA ELECTRONICS, INC.

16799 SCHOENBORN ST.

NORTH HILLS, CA 91343

Product performance is limited to specified parameters. Data is subject to change without prior notice.

CSE6279S

Rev. Orig1

5/6/03

TEL: (818) 892-0761

FAX: (818) 894-5791

http://www.pca.com
