TLD21413EPXUMA1 datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> TLD21413EPXUMA1

TLD21413EPXUMA1: DescriptionLED Driver,; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size1MB，42 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

TLD21413EPXUMA1 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	TLD21413EPXUMA1	-	-	View	Buy Now

TLD21413EPXUMA1 Overview

LED Driver,

TLD21413EPXUMA1 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Infineon
package instruction	HTSSOP, SSOP14,.25
Reach Compliance Code	compliant
Factory Lead Time	26 weeks
Input properties	STANDARD
Interface integrated circuit type	LED DISPLAY DRIVER
JESD-30 code	R-PDSO-G14
length	4.9 mm
Humidity sensitivity level	2A
Multiplex display function	NO
Number of functions	1
Number of segments	9
Number of terminals	14
Maximum operating temperature	115 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC
encapsulated code	HTSSOP
Encapsulate equivalent code	SSOP14,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Filter level	AEC-Q100
Maximum seat height	1.15 mm
Maximum slew rate	3 mA
Maximum supply voltage	18 V
Minimum supply voltage	5.5 V
Nominal supply voltage	13.5 V
surface mount	YES
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	3.9 mm

Preview

Download Datasheet

View All

TLD2141-3EP

LITIX™ Basic+

Features

•

Triple channel device with integrated and protected output stages

(current sources), optimized to drive LEDs as additional low cost current

source

High output current (up to 80 mA) per channel

Very low current consumption in sleep mode

Very low output leakage when channel is “off”

Low current consumption during fault

Additional output current demand supported by LITIX™ Companion direct drive without additional

components

Intelligent fault management: up to 16 and more devices can share a common error network with only one

external resistor

Reverse polarity protection allows reduction of external components and improves system performance

at low battery/input voltages

Overload protection

Wide temperature range: -40°C <

< 150°C

Output current control via external low power resistor

Green product (RoHS compliant)

•

Potential applications

•

Cost effective “stop”/ “tail” function implementation with shared and separated LEDs per function

Turn indicators

Position, fog, rear lights and side markers

Animated light functions like wiping indicators and “welcome/goodbye” functions

Day Running Light

Interior lighting functions like ambient lighting (including RGB color control), illumination and dash board

lighting

LED indicators for industrial applications and instrumentation

Product validation

Qualified for Automotive Applications. Product Validation according to AEC-Q100/101.

Datasheet

www.infineon.com

Rev. 1.00

2018-10-09

TLD2141-3EP

LITIX™ Basic+

Table of Contents

2.1

2.2

3.1

3.2

3.3

4.1

4.2

5.1

5.1.1

5.1.2

5.2

5.2.1

5.2.2

5.2.3

5.2.4

5.2.5

5.2.6

5.2.7

5.3

5.4

6.1

6.1.1

6.1.2

6.2

6.2.1

6.2.2

6.3

7.1

7.2

7.3

7.4

Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Pin configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Pin assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Pin definitions and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

General product characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Absolute maximum ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Functional range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Thermal resistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Internal supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Electrical characteristics internal supply and EN pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Power stages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Thermal protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Reverse battery protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Output configuration via IN_SET, OUT_SET and PWMI pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

IN_SET pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Output current adjustment via

SET

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Output control via IN_SET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

IN_SET pin behavior during device fault management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

OUT_SET pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Direct control of PWMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Timing diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Electrical characteristics power stage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Electrical characteristics IN_SET, OUT_SET and PWMI pins for output settings . . . . . . . . . . . . . . . . .

Load diagnosis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Error management via ERRN and D-pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

ERRN pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

D-pin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Open Load (OL) and short OUTx to GND (SC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Fault management (D-pin open or connected with a capacitor to GND) . . . . . . . . . . . . . . . . . . . . .

Fault management (D-pin connected to GND) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Electrical characteristics: Load diagnosis and Overload management . . . . . . . . . . . . . . . . . . . . . . . . .

PWM control (Digital dimming) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PWM unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Direct control of PWMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Timing diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Electrical characteristics PWM engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Application information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Package outline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Datasheet

Rev. 1.00

2018-10-09

TLD21413EPXUMA1 Related Products

	TLD21413EPXUMA1	TLD2141-3EP
Description	LED Driver,	LED Driver,
Is it Rohs certified?	conform to	conform to
Maker	Infineon	Infineon
package instruction	HTSSOP, SSOP14,.25	HTSSOP, TSSOP14,.25
Reach Compliance Code	compliant	compli
Input properties	STANDARD	STANDARD
Interface integrated circuit type	LED DISPLAY DRIVER	LED DISPLAY DRIVER
JESD-30 code	R-PDSO-G14	R-PDSO-G14
length	4.9 mm	4.9 mm
Humidity sensitivity level	2A	2A
Multiplex display function	NO	NO
Number of functions	1	1
Number of segments	9	3
Number of terminals	14	14
Maximum operating temperature	115 °C	115 °C
Minimum operating temperature	-40 °C	-40 °C
Package body material	PLASTIC	PLASTIC/EPOXY
encapsulated code	HTSSOP	HTSSOP
Encapsulate equivalent code	SSOP14,.25	TSSOP14,.25
Package shape	RECTANGULAR	RECTANGULAR
Package form	SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH	SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED
Filter level	AEC-Q100	AEC-Q100
Maximum seat height	1.15 mm	1.15 mm
Maximum slew rate	3 mA	3 mA
Maximum supply voltage	18 V	18 V
Minimum supply voltage	5.5 V	5.5 V
Nominal supply voltage	13.5 V	13.5 V
surface mount	YES	YES
Temperature level	INDUSTRIAL	INDUSTRIAL
Terminal form	GULL WING	GULL WING
Terminal pitch	0.65 mm	0.65 mm
Terminal location	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED
width	3.9 mm	3.9 mm
