LPC
choke coil inductor
EU
features
•
Small size allows for high mounting density
•
Operating temperature: LPC9040E: -40°C ~ +125°C,
all others: -40°C ~ +85°C
•
Large DC current capacity with low DC resistance
•
Polarity identification available
•
E-6 series of values (customs available)
•
Marking: Black body color with no marking
•
Products with lead-free terminations meet
EU RoHS requirements
•
AEC-Q200 Qualified (LPC4045 only)
dimensions and construction
E
D
F
C
F
Electrode
4045, 10065, 12065
B
45°±6°
C
A
F
Ferrite
Core
9040N, 9040E
D
Magnet Ceramic
Wire
Substrate
Electrode
Coil Temperature Rise
∆T
Inductance Change Ratio
∆L/L
D
Ceramic Magnet
Substrate Wire
Ferrite
Core
A
B
Size
4045
9040N
9040E
10065
12065
A
B
Dimensions
inches
(mm)
D
C
E
.138
(3.5)
––
––
.354
(9.0)
.433
(11.0)
F
.039±.112
(1.0±0.3)
.079±.008
(2.0±0.2)
.079±.008
(2.0±0.2)
.098±.008
(2.5±0.2)
.146±.112
(3.7±0.3)
ø.157±.008 .169±.009 .177±.008 .118±.008
(ø4.0±0.2) (4.3±0.2) (4.5±0.2) (3.0±0.2)
ø.354±.004. .193 Max. .402 Max. .079±.008
(ø9.0±0.1) (4.9 Max.) (10.2 Max.) (2.0±0.2)
ø.354±.004. .193 Max. .402 Max. .071±.008
(ø9.0±0.1) (4.9 Max.) (10.2 Max.) (1.8±0.2)
ø.394±.008 .295 Max. .409±.008 .315±.008
(ø10.0±0.2) (7.5 Max.) (10.4±0.2) (8.0±0.2)
ø.472±.008 .295 Max. .488±.008 .472±.008
(ø12.0±0.2) (7.5 Max.) (12.4±0.2) (10.0±0.2)
R
1
Coil Temperature
LPC4045/LPC9040N/
LPC10065/LPC12065 LPC9040E
+20°C
+40°C
-10%
-10%
ordering information
New Part #
LPC
Type
4045
Size
4045
9040N
9040E
10065
12065
A
Termination
Material
A: SnAg
TED
Packaging
TED: 10" embossed plastic
(4045 - 1,000 pieces/reel)
(9040N - 500 pieces/reel)
(9040E - 500 pieces/reel)
(10065 - 300 pieces/reel)
(12065 - 300 pieces/reel)
101
Nominal
Inductance
101: 100µH
221: 220µH
152: 1500µH
K
Tolerance
K: ±10%
M:±20%
N: ±30%
For further information
on packaging, please
refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
1/27/14
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
217
inductors
LPC
choke coil inductor
applications and ratings
(continued)
Part
Designation
LPC10065ATE680K
LPC10065ATE101K
LPC10065ATE151K
LPC10065ATE221K
LPC10065ATE331K
LPC10065ATE471K
LPC10065ATE681K
LPC10065ATE102K
LPC10065ATE152K
LPC10065ATE222K
LPC10065ATE332K
LPC12065ATER68N
LPC12065ATE1R0N
LPC12065ATE1R5N
LPC12065ATE2R2N
LPC12065ATE3R3M
LPC12065ATE4R7M
LPC12065ATE6R8M
LPC12065ATE100K
LPC12065ATE150K
LPC12065ATE220K
LPC12065ATE330K
LPC12065ATE470K
LPC12065ATE680K
LPC12065ATE101K
LPC12065ATE151K
LPC12065ATE221K
LPC12065ATE331K
LPC12065ATE471K
LPC12065ATE681K
LPC12065ATE102K
LPC12065ATE152K
LPC12065ATE222K
LPC12065ATE332K
LPC12065ATE472K
LPC12065ATE682K
Inductance
(µH)
68
100
150
220
330
470
680
1.0 mH
1.5 mH
2.2 mH
3.3 mH
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
1.0 mH
1.5 mH
2.2 mH
3.3 mH
4.7 mH
6.8 mH
Inductance
Tolerance
Quality
Factor
Minimum
(MHz)
Self Resonant
Frequency
Minimum
(MHz)
5.0
4.0
3.0
2.5
2.0
1.5
1.0
0.95
0.85
0.70
0.55
77.0
60.0
47.0
38.0
30.0
24.0
19.0
15.0
12.0
9.5
7.5
6.2
4.9
4.0
3.2
2.5
2.0
1.6
1.3
1.0
0.83
0.67
0.53
0.43
0.34
DC
Resistance
Maximum
(Ω)
0.255
0.380
0.580
0.850
1.30
1.85
2.70
4.00
6.10
9.00
13.5
5.0 m
7.0 m
8.0 m
10.0 m
0.012
0.016
0.022
0.031
0.046
0.065
0.093
0.130
0.182
0.260
0.380
0.540
0.790
1.08
1.55
2.21
3.20
4.60
6.60
9.30
13.2
Allowable
DC Current
Maximum
(Amps)
1.48
1.22
1.00
0.82
0.67
0.57
0.47
0.38
0.31
0.26
0.21
10.0
9.50
9.00
8.00
7.00
6.50
5.40
4.50
3.63
3.00
2.40
2.05
1.70
1.38
1.14
0.94
0.77
0.65
0.53
0.44
0.35
0.29
0.23
0.19
0.16
Measured
Frequency
(Hz)
K: ±10%
30
100 MHz
inductors
N: ±30%
40
M: ±20%
30
2.52 MHz
20
K: ±10%
15
100 KHz
30
Allowable current is a DC Current which causes initial inductance to decrease by 10%. Or coil temperature to rise by 40°C, whichever is smaller
Operating Temperature Range: -40°C ~ +125°C (Self-heating is included). That the operating temperature upper limit temperature of the coil winding
portions (ambient temperature + self-heating) is (+125°C) or less.
environmental applications
Performance Characteristics
Performance Requirements
∆L/L
Parameter
High Temperature Exposure
Low Temperature Exposure
Moisture Exposure
Temperature Cycling
Limit
±5%
±5%
±5%
±5%
Typical
±1.3%
±1.3%
±1.6%
±1.3%
Test Method
LPC4045, LPC9040N, LPC10065, LPC12065: +85°C ± 2°C, 500 hours
LPC9040E: +125°C ± 2°C, 500 hours
-40°C±2°C, 500 hours
+40°C, 90 - 95% RH, 500 hours
LPC4045, LPC9040N, LPC10065, LPC12065: -40°C (30 minutes)/
+85°C (30 minutes), 100 cycles
LPC9040E: -40°C (30 minutes)/+125°C (30 minutes), 100 cycles
Surface Temperature Rise graphs and additional environmental applications can also be found at www.koaspeer.com
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
1/03/14
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
219
