IllumInatIon
luXEon 3030 HE Plus
Industry leading efficacy, 3V 3030 package
LUXEON 3030 HE Plus is a superior, high efficacy, mid power package
built on the legacy of the LUXEON 3030 product line. It serves as a go-to
solution for various indoor and outdoor fixture applications that require
top notch lm/W performance and long lifetime. LUXEON 3030 HE Plus
adopts quadrant bin structure within 3 SDCM, which enables 2 SDCM
by kitting.
FEaturEs and BEnEFIts
Superior high efficacy at rated current enables outstanding lm/W
at system level
Reliable package design from a proven product line affirms application
long lifetime
Quadrant bin structure within 3 SDCM enables 2 SDCM by kitting
Industry standard package allows drop-in replacement for existing
3030 packages
PrImary aPPlIcatIons
Panel / Soft Lights
Spotlights
Linear
Troffers
Downlights
Wall Pack
DS267 LUXEON 3030 HE Plus Product Datasheet ©2020 Lumileds Holding B.V. All rights reserved.
No. E507562
Table of Contents
General Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Test Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Part Number Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Lumen Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Environmental Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Performance Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Selection Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Optical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Electrical and Thermal Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Absolute Maximum Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Characteristics Curves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Spectral Power Distribution Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Light Output Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Forward Current Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Radiation Pattern Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Product Bin and Labeling Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Decoding Product Bin Labeling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Luminous Flux Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Color Bin Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Forward Voltage Bins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Mechanical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Reflow Soldering Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
JEDEC Moisture Sensitivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Solder Pad Design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Packaging Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Pocket Tape Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Reel Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
DS267 LUXEON 3030 HE Plus Product Datasheet 20200424 ©2020 Lumileds Holding B.V. All rights reserved.
i
General Product Information
Product Test Conditions
LUXEON 3030 HE Plus LEDs are tested and binned with a 20ms monopulse of 65mA at a junction temperature, T
j
, of 25°C.
Part Number Nomenclature
Part numbers for LUXEON 3030 HE Plus follow the convention below:
L 1 3 0 –
A A B B
H A 3 0 0 0 0
C D
Where:
A A
–
B B
–
C
D
–
–
designates nominal CCT (27=2700K, 30=3000K, 35=3500K, 40=4000K, 50=5000K, 57=5700K, 65=6500K)
designates minimum CRI (70=70CRI, 80=80CRI, 90=90CRI)
designates product code (0=0.08V V
f
bin, B=0.1V V
f
bin)
designates Lumileds internal code (i.e. 1, 2, 3, etc., share the same base part)
Therefore, the following part number is used for a LUXEON 3030 HE Plus, 3000K 80CRI LED with a 0.1V V
f
bin:
L 1 3 0 –
3 0 8 0
H A 3 0 0 0 0
B 1
Lumen Maintenance
Please contact your local Sales Representative or Lumileds Technical Solutions Manager for more information about the long-
term performance of this product.
Environmental Compliance
Lumileds LLC is committed to providing environmentally friendly products to the solid-state lighting market. LUXEON 3030 HE
Plus is compliant to the European Union directives on the restriction of hazardous substances in electronic equipment, namely
the RoHS Directive 2011/65/EU and REACH Regulation (EC) 1907/2006. Lumileds LLC will not intentionally add the following
restricted materials to its products: lead, mercury, cadmium, hexavalent chromium, polybrominated biphenyls (PBB)
or polybrominated diphenyl ethers (PBDE).
DS267 LUXEON 3030 HE Plus Product Datasheet 20200424 ©2020 Lumileds Holding B.V. All rights reserved.
2
Performance Characteristics
Product Selection Guide
Table 1 . Product performance of LUXEON 3030 HE Plus at 65mA, T
j
= 25°C .
nomInal
cct
[1]
2700K
3000K
3500K
4000K
5000K
5700K
6500K
3000K
3500K
4000K
5000K
5700K
6500K
2700K
3000K
3500K
4000K
5000K
5700K
6500K
2700K
3000K
3500K
4000K
5000K
5700K
6500K
mInImum
crI
[1, 2]
80
80
80
80
80
80
80
70
70
70
70
70
70
80
80
80
80
80
80
80
90
90
90
90
90
90
90
lumInous FluX
[1, 2]
(lm)
mInImum
30.0
32.0
33.0
34.0
34.0
33.5
33.0
34.0
35.0
36.0
36.0
35.0
34.5
30.0
32.0
33.0
34.0
34.0
33.5
33.0
26.0
27.0
27.5
28.5
28.5
28.5
28.0
tyPIcal
65ma
33.5
35.0
36.0
37.0
37.0
36.5
36.0
37.0
38.0
39.0
39.0
38.0
37.5
33.5
35.0
36.0
37.0
37.0
36.5
36.0
28.5
29.5
30.5
31.5
31.5
31.5
31.0
190
199
204
210
210
207
204
210
216
221
221
216
213
190
199
204
210
210
207
204
162
167
173
179
179
179
176
L130-2780HA3000001
L130-3080HA3000001
L130-3580HA3000001
L130-4080HA3000001
L130-5080HA3000001
L130-5780HA3000001
L130-6580HA3000001
L130-3070HA30000B1
L130-3570HA30000B1
L130-4070HA30000B1
L130-5070HA30000B1
L130-5770HA30000B1
L130-6570HA30000B1
L130-2780HA30000B1
L130-3080HA30000B1
L130-3580HA30000B1
L130-4080HA30000B1
L130-5080HA30000B1
L130-5780HA30000B1
L130-6580HA30000B1
L130-2790HA30000B1
L130-3090HA30000B1
L130-3590HA30000B1
L130-4090HA30000B1
L130-5090HA30000B1
L130-5790HA30000B1
L130-6590HA30000B1
tyPIcal
lumInous
EFFIcacy (lm/W)
Part numBEr
Notes for Table 1:
1. Luminous flux, CCT, and CRI are specified at T
j
=25°C. Typical CRI is approximately 2 points higher than the minimum CRI specified, but this is not guaranteed.
2. Lumileds maintains a tolerance of ±2 on CRI and ±7.5% on luminous flux measurements.
Optical Characteristics
Table 2 . Optical characteristics for LUXEON 3030 HE Plus at 65mA, T
j
= 25°C .
Part numBEr
L130-xxxxHA30000x1
tyPIcal total IncludEd anGlE
[1]
160°
tyPIcal VIEWInG anGlE
[2]
110°
Notes for Table 2:
1. Total angle at which 90% of total luminous flux is captured.
2. Viewing angle is the off axis angle from the LED centerline where the luminous intensity is ½ of the peak value.
DS267 LUXEON 3030 HE Plus Product Datasheet 20200424 ©2020 Lumileds Holding B.V. All rights reserved.
3
Electrical and Thermal Characteristics
Table 3 . Electrical and thermal characteristics for LUXEON 3030 HE Plus at 65mA, T
j
= 25°C .
Part numBEr
L130-xxxxHA3000001
L130-xxxxHA30000B1
ForWard VoltaGE
[1]
(V
f
)
mInImum
2.62
2.66
tyPIcal
2.71
2.71
maXImum
2.86
2.76
tyPIcal tEmPEraturE
coEFFIcIEnt oF ForWard
VoltaGE
[2]
(mV/°c)
-1.0 to -2.0
-1.0 to -2.0
tyPIcal tHErmal
rEsIstancE—JunctIon
to soldEr Pad (°c/W)
10.0
10.0
Notes for Table 3:
1. Lumileds maintains a tolerance of ±0.1V on forward voltage measurements.
2. Measured between 25°C and 85°C.
Absolute Maximum Ratings
Table 4 . Absolute maximum ratings for LUXEON 3030 HE Plus .
ParamEtEr
DC Forward Current
[1]
Peak Pulsed Forward Current
[2]
ESD Sensitivity (ANSI/ESDA/JEDEC JS-001-2012)
LED Junction Temperature (DC & Pulse)
Operating Case Temperature
LED Storage Temperature
Soldering Temperature
Allowable Reflow Cycles
Reverse Voltage (V
reverse
)
[3]
maXImum PErFormancE
480mA
700mA
Class 2
125°C
-40°C to 105°C
-40°C to 105°C
JEDEC 020D 260°C
3
-5V
Notes for Table 4:
1. Residual periodic variations due to power conversion from alternating current (AC) to direct current (DC), also called “ripple”, are acceptable if the following conditions are met:
– The frequency of the ripple current is 100Hz or higher
– The average current for each cycle does not exceed the maximum allowable DC forward current
– The maximum amplitude of the ripple does not exceed 25% of the maximum allowable DC forward current
2. Pulse operation with the maximum peak pulse forward current is acceptable if the pulse on time is ≤5ms per cycle and the duty cycle is ≤50%
3. At a maximum reverse current of 10µA. LUXEON 3030 2D LEDs are not designed to be driven in reverse bias.
DS267 LUXEON 3030 HE Plus Product Datasheet 20200424 ©2020 Lumileds Holding B.V. All rights reserved.
4
