C4700
Typical Applications
CDMA2000 and UMTS Base Stations
Test and Measurement Equipment
OCXO
Features
Ultra-High Stability
Excellent Temperature Stability
SC-Cut Crystal Crystal
4895, OC-050, CO-330
Previous Vectron Model Numbers
Frequency range
Standard frequencies
4 MHz – 15 MHz
5; 10; 15MHz
Frequency stabilities
1
[SC Cut Crystal – Standard]
Parameter
vs. operating temperature range
(peak to peak stability)
Parameter
Initial tolerance
vs. supply voltage change
vs. load change
vs. aging /1 day
vs. aging /1 day
vs aging /1 Year
vs. aging / year (following years)
Warm-up Time
Min
-0.4
-0.2
-0.4
Min
-50
-0.1
-0.1
-0.5
-0.2
-20
-10
Typ
Max.
+0.4
+0.2
+0.4
Max.
+50
+0.1
+0.1
+0.5
+0.2
+20
+10
5
Units
ppb
ppb
ppb
Units
ppb
ppb
ppb
ppb
ppb
ppb
minutes
Operating temp
Ordering Code
range
0 … +70°
C
C049
0 … +70°
C
C029
-20 … +70°
C
D049
Condition
at time of shipment, nominal EFC
V
S
± 5%
Load ± 5%
after 72 hours of operation
after 7 days of operation
after 72 hours of operation
to
±
10ppb of final frequency (1 hour reading) @
+25°
C
Typ
Supply voltage (Vs)
Parameter
Supply voltage [Standard]
Supply voltage [Standard]
Power consumption @+12V
Power consumption @+5V
Min
11.4
4.75
Typ
12.0
5.0
Max.
12.6
5.25
12
4
10
4
Units
VDC
VDC
Watts
Watts
Watts
Watts
Condition
Ordering Code
SV120
SV050
during warm-up
steady state @ +25°
C
during warm-up
steady state @ +25°
C
RF output
Parameter
Signal [Standard]
Load
Signal Level (Vol)
Signal Level (Voh)
Duty cycle
Signal [Option]
Load
Output Power
Harmonics
Sub-Harmonics
Min
Typ
HCMOS
15
0.5
4.5
45
55
Sinewave
50
+7.0
+9.0
-30
-40
pF
VDC
VDC
%
Max.
Units
Condition
Ordering Code
RFH
15pF load
15pF load
@ (Voh-Vol)/2
RFS
dBm
dBc
dBc
50 Ohm load
50 Ohm load
50 Ohm load
+5.0
