INTERCONNECTS
SERIES 410, 411, 415 • 2,54 GRID SOLDER TAIL •
DOUBLE ROW STRIPS
Number of Pins X 2,54 /2
•
Series 41X double row strip sockets are on
2,54 grid
5,08
2,54
2,54
•
Various solder tails available: standard length,
long for multi-layer boards, very low and ultra
low profile. See Mill-Max #1001, #0134, #0501
or #1534 pins. See pages 161, 162 and 165
for details
0,38-0,64
0,25 * 0,46
3,71
2,41
2,79
4,19
•
Hi-Rel, 4-finger BeCu #12 and #30 contact are
rated at 3 amps. See pages 252 and 253 for
details
0,51 DIA.
3,18
2,54
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
FIG. 1
0,38-0,64
0,25 * 0,46
ORDERING INFORMATION
Series 410...001
4,19
Standard Solder Tail
410-XX-2_ _-41-001000
3,81
2,62
2,79
FIG. 1
Series 411...001
0,51 DIA.
Specify number of pins
4,32
04-64
Long Solder Tail
411-XX-2_ _-41-001000
2,54
FIG. 2
0,38-0,64
0,25 * 0,46
FIG. 2
Series 415...001
3,1
Specify number of pins
04-64
Very Low Profile
415-XX-2_ _-41-001000
3,84
2,44
2,79
FIG. 3
Series 415...003
Specify number of pins
0,76 DIA.
2,74
04-64
Ultra Low Profile
415-XX-2_ _-41-003000
2,54
FIG. 4
FIG. 3
PAGE 66 | INTERCONNECTS
0,38-0,56
0,25 * 0,46
Specify number of pins
04-64
1,8
3,94
1,8
2,41
2,41
2011/65/EU
RoHS - 2
XX=Plating Code
See Below
11
13
91
93
For
Electrical, Mechanical
& Enviromental Data,
See page 264
2,54
SPECIFY PLATING CODE XX=
Sleeve
(Pin)
Contact
(Clip)
41
43
FIG. 4
0,25μm
Au
0,25μm
Au
5,08μm
Sn/Pb
5,08μm
Sn/Pb
5,08μm
Sn
5,08μm
Sn
0,25μm
Au
0,76μm
Au
0,25μm
Au
0,76μm
Au
0,25μm
Au
0,76μm
Au
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
