RFM products are now
Murata products.
RO3300E
•
•
•
•
Designed for 403.55 MHz MICs Transmitters
Very Low Series Resistance
Quartz Stability
Complies with Directive 2002/95/EC (RoHS)
Pb
403.55 MHz
SAW Resonator
The RO3300E is a true one-port, surface-acoustic-wave (SAW) resonator in a surface-mount, ceramic case.
It provides reliable, fundamental-mode, quartz frequency stabilization of fixed-frequency transmitters
operating at 403.55 MHz.
Absolute Maximum Ratings
Rating
Input Power Level
DC Voltage
Storage Temperature Range
Operating Temperature Range
Soldering Temperature (10 seconds / 5 cycles maximum)
Value
0
12
-40 to +125
-40 to +105
260
Units
dBm
VDC
°C
°C
°C
SM3030-6 Case
3.0 X 3.0
Electrical Characteristics
Characteristic
Center Frequency, +25 °C
Insertion Loss
Quality Factor
Temperature Stability
Unloaded Q
50
Ω
Loaded Q
Turnover Temperature
Turnover Frequency
Frequency Temperature Coefficient
Frequency Aging
RF Equivalent RLC Model
Absolute Value during the First Year
Motional Resistance
Motional Inductance
Motional Capacitance
Shunt Static Capacitance
Test Fixture Shunt Inductance
Lid Symbolization (in addition to Lot and/or Date Codes)
Standard Reel Quantity
Reel Size 7 Inch
Reel Size 13 Inch
DC Insulation Resistance between Any Two Terminals
Absolute Frequency
Tolerance from 403.55 MHz
Sym
f
C
Δf
C
IL
Q
U
Q
L
T
O
f
O
FTC
|f
A
|
R
M
L
M
C
M
C
O
L
TEST
Notes
2,3,4,5
2,5,6
5,6,7
Minimum
403.475
Typical
Maximum
403.625
±75
Units
MHz
kHz
dB
1.0
8117
768
10
25
f
C
0.032
≤10
1.0
10.5
33.5
4.6
4.2
36.9
719 // YWWS
500 Pieces/Reel
3000 Pieces/Reel
2.0
40
°C
ppm/°C
2
ppm/yr
MΩ
Ω
µH
fF
pF
nH
6,7,8
1
5
5, 7, 9
5, 6, 9
2, 7
10
CAUTION: Electrostatic Sensitive Device. Observe precautions for handling.
NOTES:
1.
Aging may exceed the specification for prolonged temperatures above +65 °C.
Typically, aging is greatest the first year after manufacture, decreasing in subse-
quent years.
The center frequency, f
C
, is measured at the minimum insertion loss point, IL
MIN
,
with the resonator in the 50
Ω
test system (VSWR
≤
1.2:1). The shunt
inductance, L
TEST
, is tuned for parallel resonance with C
O
at f
C
. Typically,
f
OSCILLATOR
or f
TRANSMITTER
is approximately equal to the resonator f
C
.
One or more of the following United States patents apply: 4,454,488 and
4,616,197.
Typically, equipment utilizing this device requires emissions testing and
government approval, which is the responsibility of the equipment manufacturer.
Unless noted otherwise, case temperature T
C
= +25 ± 2 °C.
The design, manufacturing process, and specifications of this device are subject
to change without notice.
F
requency aging is the change in f
C
with time and is specified at +65 °C or less.
7.
8.
2.
9.
3.
4.
5.
6.
10.
Derived mathematically from one or more of the following directly measured
parameters: f
C
, IL, 3 dB bandwidth, f
C
versus T
C
, and C
O
.
Turnover temperature, T
O
, is the temperature of maximum (or turnover)
frequency, f
O
. The nominal frequency at any case temperature, T
C
, may be
calculated from: f = f
O
[1 - FTC (T
O
-T
C
)
2
]. Typically
oscillator
T
O
is
approximately equal to the specified
resonator
T
O
.
This equivalent RLC model approximates resonator performance near the
resonant frequency and is provided for reference only. The capacitance C
O
is
the static (nonmotional) capacitance between the two terminals measured at low
frequency (10 MHz) with a capacitance meter. The measurement includes
parasitic capacitance with "NC” pads unconnected. Case parasitic capacitance
is approximately 0.05 pF. Transducer parallel capacitance can by calculated as:
C
P
≈
C
O
- 0.05 pF.
Tape and Reel Standard Per ANSI / EIA 481.
©2010-2015 by Murata Electronics N.A., Inc.
RO3300E (R) 2/11/15
Page 1 of 2
www.murata.com
Electrical Connections
The SAW resonator is bidirectional and
may be installed with either orientation.
The two terminals are interchangeable
and unnumbered. The callout NC
indicates no internal connection. The NC
pads assist with mechanical positioning
and stability. External grounding of the NC
pads is recommended to help reduce
parasitic capacitance in the circuit.
B
1
6
C
Pin
1
2
3
4
5
6
NC
Connection
Terminal
NC
NC
NC
Temperature Characteristics
The curve shown accounts for resonator contribution only and does not
include external LC component temperature effects.
f
C
= f
O
, T
C
= T
O
0
(f-fo ) / fo (ppm)
0
-50
-100
-150
-200
0 +20 +40 +60 +80
Terminal
-50
-100
-150
-200
-80 -60 -40 -20
G
6
H
1
Δ
T = T
C
- T
O
( °C )
I
A 2
5
E
F
5
2
Characterization Test Circuit
Inductor L
TEST
is tuned to resonate with the static capacitance, C
O
, at F
C
.
3
4
D
4
J
3
6
1
From 50
Ω
Network Analyzer
5
2
To 50
Ω
Network Analyzer
4
3
K
L
N
K
N
O
N
M
M
Power Dissipation Test
P
INCIDENT
Case and Typical PCB Land Dimensions
Ref
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
Min
2.87
2.87
1.12
0.77
2.67
1.47
0.72
1.37
0.47
1.17
mm
Nom
3.00
3.00
1.25
0.90
2.80
1.60
0.85
1.50
0.60
1.30
3.20
1.70
1.05
0.81
0.38
Max
3.13
3.13
1.38
1.03
2.93
1.73
0.98
1.63
0.73
1.43
Min
0.113
0.113
0.044
0.030
0.105
0.058
0.028
0.054
0.019
0.046
Inches
Nom
0.118
0.118
0.049
0.035
0.110
0.063
0.033
0.059
0.024
0.051
0.126
0.067
0.041
0.032
0.015
Max
0.123
0.123
0.054
0.040
0.115
0.068
0.038
0.064
0.029
0.056
50
Ω
Source
at F
C
P
REFLECTED
Low-Loss
Matching
Network to
50
Ω
1
6
2
5
3
4
Example Application Circuits
Typical Low-Power Transmitter Application
200k
Ω
C1
L1
(Antenna)
Modulation
Input
+9VDC
47
1
6
ROXXXXC
Bottom View
2
5
3
4
C2
RF Bypass
470
Typical Local Oscillator Application
200k
Ω
+VDC
C1
L1
Output
+VDC
Equivalent RLC Model
0.05 pF*
Co = Cp + 0.05 pF
*Case Parasitics
ROXXXXC
Bottom View
1
6
2
5
3
4
C2
RF Bypass
Cp
Rm
Lm
Cm
©2010-2015 by Murata Electronics N.A., Inc.
RO3300E (R) 2/11/15
Page 2 of 2
www.murata.com
