1KSMB SERIES
1000 Watts Suface Mount Transient Voltage Suppressor
FEATURES
* Peak pulse power:1000 W (10/1000 μs)
* Plastic package has underwriters laboratory
* Glass passivated chip construction
* 1000 watt surage capability at 1ms
* Excellent clamping capability
* Low zener impedance
* Fast response time
* P/N suffix V means AEC-Q101 qualified, e.g:1KSMB10AV
* P/N suffix V means Halogen-free
0.088 (2.15)
0.055 (1.40)
0.190 (4.65)
0.160 (4.06)
0.155 (3.94)
0.130 (3.30)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
0.111 (2.82)
0.082 (2.10)
0.060 (1.52)
0.030 (0.76)
0.220 (5.59)
0.195 (4.95)
0.012 (0.305)
0.006 (0.152)
0.0085(0.230)Max
Dimensions in inches and (millimeters)
NOTES : 1. Non-repetitive current pulse, per Fig.3 and derated above T
A
= 25
o
C per Fig.2.
2. V
F
= 3.5V for devices of Vbr≤ 50V and V
F
= 5.0V Max for devices of Vbr 50V .
2019-12/31
REV:B
PACKAGING OF DIODE AND BRIDGE RECTIFIERS
REEL PACK
PACKAGE
SMB
PACKING
EA PER EA PER COMPONENT TAPE SPACE REEL DIA CARTON SIZE EA PER
GROSS
SPACE
INNER
REEL
CARTON WEIGHT(Kg)
CODE
(mm)
(mm)
(mm)
(mm)
BOX
-W/-T
3,000
6,000
---
---
330
360*355*360
48,000
13.90
