F-213 SUPPLEMENT
®
EQRP–018–08.00–STR–TTL–1
(0,80 mm) .0315"
EQRP SERIES
Q RATE TWINAX CABLE ASSEMBLY
SPECIFICATIONS
i
For complete specifications and
recommended PCB layouts see
www.samtec.com?EQRP
Cable:
32 AWG twinax
micro ribbon
Signal Routing:
100Ω Differential
Cable Bending Radius:
(11,11 mm) 7/16" min
Plating:
Au over 50µ" (1,27 µm) Ni
Current Rating:
.6 Amps per contact (600 mA)
Propagation Delay:
4.67 nsec/meter
Operating Temp Range:
-25°C to +105°C
Skew (pair-to-pair):
<10 ps/ft
Skew (within a pair):
<5 ps/ft
EMI Performance:
FCC Class A
RoHS Compliant:
Yes
Rated @ 7dB
Insertion Loss
®
Mates with:
QRF8-DP, QRM8-DP
Edge Rate
™
contacts
ls
toco d
Pro orte
Supp
SAS
SATA
el
Fibre Chann
Ethernet
®
PCIe
™
InfiniBand
Differential
routing
32 AWG twinax
ribbon cable
t report at
Download tes
om?EQRP
www.samtec.c
Patent Pending
Integral
ground/
power plane
Slim
body design
™
Cable
Length
EQRP
NO. OF
PAIRS
WIRE
LENGTH
END
NO. 1
END
NO. 2
WIRING
OPTION
SCREW
OPTION
EQRP
6" (152,4 mm)
5.82 GHz / 11.64 Gbps
39.37" ( 1 m)
5.10 GHz / 10.20 Gbps
Performance data for other cable
lengths and complete test data
available at www.samtec.com?EQRP
or contact sig@samtec.com
–018, –036, –054
(Number of Pairs)
–“XX.XX”
= Wire Length in Inches
(43,7 mm) 01.72" minimum
–TTR
= Terminal, Top Right
–1
= Pin 1 to
Pin 1
Leave
blank for
no Screw
Option
–TTL
= Terminal, Top Left
–2
= Pin 1 to
Pin 2
OAL = Wire Length + (20,82) .820
–F
= Screw
option
(First end
only)
–TBR
APPLICATIONS
11.5 mm
or
14.45 mm
N-1
N
N
N-1
= Terminal, Bottom Right
–3
= Pin 1 to
Pin N-1
–TBL
= Terminal, Bottom Left
D
C
A
–S
= Screw
option
(Second
end only)
–STR
= Socket, Top Right
–4
= Pin 1 to
Pin N
Processing conditions will
affect mated height.
–STL
= Socket, Top Left
–B
= Screw
option
(Both
ends)
–SBR
Note:
Cable lengths longer than
40.00" (1 meter) are not
supported with S.I. test data.
Note:
Verify part number and correct
wiring scheme with Samtec’s
Interactive Cable Builder at
www.samtec.com/cable_
builder/pitch.aspx
Note:
Some lengths, styles and
options are non-standard,
non-returnable.
= Socket, Bottom Right
01
01
02
02
(3,28) .129 DIA
(5,08) .200
(18,93)
.745
–SBL
= Socket, Bottom Left
NO. OF
POSITIONS
A
(33,02)
1.300
(57,81)
2.276
(82,63)
3.253
C
(39,12)
1.540
(63,91)
2.516
(88,70)
3.492
D
(46,74)
1.840
(71,53)
2.816
(96,32)
3.792
(12,44)
.490
(11,12)
(7,62) .438
.300
–018
–036
–054
END NO.1 (–F SHOWN)
END NO.2
WWW.SAMTEC.COM
