BNC75 Series
75Ω BNC Type Connectors
●
BNC75 series are connectors for 75 Ω group of
BNC series (50Ω group).
●
Intermateable with BNC series.
●
Easy interface is established between test
instruments, broadcasting eqipment, CATV and
HDTV by bayonet lock mechanism.
SPECIFICATION
Characteristic Impedance
Dielectric withstanding voltage
Insulation resistance
Contact resistance
VSWR
75Ω
1500V AC (rms) for 1 minute
1000MΩmin. at 500V DC
3mΩ max.
1.3max. at DC½1GHz
Specifications depends on each connector although these are basic specifications.
MATERIAL/FINISH
Shell (Body)
Contact (male)
Contact (female)
Insulators
Gaskets
Copper alloy/Nickel or Silver plating
Copper alloy/Silver or Gold plating
Copper alloy/Silver or Gold plating
PTFE
Silicone rubber
Please ask us for the cable assemblies to assure its performance.
●
●
