SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 5345, REV. -
1C6103A thru 1C6137/A
500W Transient Voltage Suppressor Diode Chip/Die
Operating and Storage Temperature: -55
o
C to +175
o
C
SERIES
TYPE
500W
1C6103A
1C6104
1C6104A
1C6105
1C6105A
1C6106
1C6106A
1C6107
1C6107A
1C6108
1C6108A
1C6109
1C6109A
1C6110
1C6110A
1C6111
1C6111A
1C6112
1C6112A
1C6113
1C6113A
1C6114
1C6114A
1C6115
1C6115A
1C6116
1C6116A
1C6117
1C6117A
1C6118
1C6118A
1C6119
1C6119A
1C6120
1C6120A
1C6121
1C6121A
1C6122
1C6122A
1C6123
1C6123A
1C6124
1C6124A
MIN
BREAKDOWN
VOLTAGE
V(BR) @ I(BR)
Vdc
7.13
7.38
7.79
8.19
8.65
9
9.5
9.9
10.45
10.8
11.4
11.7
12.35
13.5
14.25
14.4
15.2
16.2
17.1
18
19
19.8
20.9
21.6
22.8
24.3
25.7
27
28.5
29.7
31.4
32.4
34.2
35.1
37.1
38.7
40.9
42.3
44.7
45.9
48.5
50.4
53.2
mA dc
175
150
150
150
150
125
125
125
125
100
100
100
100
75
75
75
75
65
65
65
65
50
50
50
50
50
50
40
40
40
40
30
30
30
30
30
30
25
25
25
25
20
20
WORKING
PEAK
REVERSE
VOLTAGE
VRWM
Vdc
5.7
6.2
6.2
6.9
6.9
7.6
7.6
8.4
8.4
9.1
9.1
9.9
9.9
11.4
11.4
12.2
12.2
13.7
13.7
15.2
15.2
16.7
16.7
18.2
18.2
20.6
20.6
22.8
22.8
25.1
25.1
27.4
27.4
29.7
29.7
32.7
32.7
35.8
35.8
38.8
38.8
42.6
42.6
MAXIMUM
REVERSE
CURRENT
IR1
Adc
50
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
MAX. CLAMP.
VOLTAGE
VC @ IP
tp = 1ms
V(pk)
11.2
12.7
12.1
14
13.4
15.2
14.5
16.3
15.6
17.7
16.9
19
18.2
21.9
21
23.4
22.3
26.3
25.1
29
27.7
31.9
30.5
34.8
33.3
39.2
37.4
43.6
41.6
47.9
45.7
52.3
49.9
56.2
53.6
62
59.1
67.7
64.6
73.5
70.1
80.7
77
MAX. PEAK
PULSE
CURRENT
IP
A(pk)
44.6
39.0
41.3
35.7
37.3
32.9
34.5
30.7
32.0
28.2
29.6
26.3
27.5
22.8
23.8
21.4
22.4
19.0
19.9
17.2
18.0
15.7
16.4
14.4
15.0
12.8
13.4
11.5
12.0
10.4
10.9
9.6
10.0
8.9
9.3
8.1
8.5
7.4
7.7
6.8
7.1
6.2
6.5
MAX. TEMP.
COEFFICIENT
V(BR)
%/ C
.06
.06
.06
0.06
0.06
0.07
0.07
0.07
0.07
0.07
0.07
0.08
0.08
0.08
0.08
0.08
0.08
0.085
0.085
0.085
0.085
0.085
0.085
0.09
0.09
0.09
0.09
0.09
0.09
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
©2012 Sensitron Semiconductor 221 West Industry Court
Deer Park, NY 11729-4681
Phone (631) 586 7600 Fax (631) 242 9798 www.sensitron.com sales@sensitron.com
SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 5345, REV. -
Mechanical Dimensions: inches
(mm)
1C6103A thru 1C6137/A
ANODE
Standard Metallization:
Top side: Al; 25 kÅ minimum
Bottom side:
Ti/Ni/Ag: 30 kÅ minimum
Gold Option Available for Top and/or Bottom Metalization:
Ti (1.2 kA) / Ni (1.8 kA) / Au (12kA)
Reversed polarity option available
ANODE
SENSITRON
SEMICONDUCTOR
CATHODE
500W TVS and
5 W Zener
Die
Diameter
A
0.090 ± 0.003
(2.286 ± 0.076)
Die Flat
to Flat
B
0.079 ± 0.003
(2.006 ± 0.076)
Metal
Diameter
C
0.072 ± 0.003
(1.829 ± 0.076)
Metal Flat
to Flat
E
0.062 ± 0.003
(1.575 ± 0.076)
Die
Thickness
Z
0.010 ± 0.001
(0.254 ± 0.025)
PART ORDERING INFORMATION
Default part number is Al top, Ag bottom.
Add the following suffix for these metal combinations:
Top
Bottom
Part Number
Al
Ag
1C6104
AG
Al
Au
1C6104AG
BB
Ag
Ag
1C6104BB
BG
Ag
Au
1C6104BG
GG
Au
Au
1C6104GG
GB
Au
Ag
1C6104GB
-R
- Reverse polarity -
1C6104-R
A = Ti (0.3 kA) / Al (25 kA)
B = Ti (1.2 kA) / Ni (1.8 kA) / Ag (30kA)
G = Ti (1.2 kA) / Ni (1.8 kA) / Au (12kA)
(TOP)
/ Ti (1.2 kA) / Ni (1.8 kA) / Au (4kA)
(BOTTOM)
Suffix
©2012 Sensitron Semiconductor 221 West Industry Court
Deer Park, NY 11729-4681
Phone (631) 586 7600 Fax (631) 242 9798 www.sensitron.com sales@sensitron.com
SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 5345, REV. -
1C6103A thru 1C6137/A
DISCLAIMER:
1- The information given herein, including the specifications and dimensions, is subject to change without prior notice to improve product
characteristics. Before ordering, purchasers are advised to contact the Sensitron Semiconductor sales department for the latest version of the
datasheet(s).
2- In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation, traffic equipment, medical
equipment , and safety equipment) , safety should be ensured by using semiconductor devices that feature assured safety or by means of users’
fail-safe precautions or other arrangement .
3- In no event shall Sensitron Semiconductor be liable for any damages that may result from an accident or any other cause during operation of
the user’s units according to the datasheet(s). Sensitron Semiconductor assumes no responsibility for any intellectual property claims or any
other problems that may result from applications of information, products or circuits described in the datasheets.
4- In no event shall Sensitron Semiconductor be liable for any failure in a semiconductor device or any secondary damage resulting from use at
a value exceeding the absolute maximum rating.
5- No license is granted by the datasheet(s) under any patents or other rights of any third party or Sensitron Semiconductor.
6- The datasheet(s) may not be reproduced or duplicated, in any form, in whole or part, without the expressed written permission of Sensitron
Semiconductor.
7- The products (technologies) described in the datasheet(s) are not to be provided to any party whose purpose in their application will hinder
maintenance of international peace and safety nor are they to be applied to that purpose by their direct purchasers or any third party. When
exporting these products (technologies), the necessary procedures are to be taken in accordance with related laws and regulations.
©2012 Sensitron Semiconductor 221 West Industry Court
Deer Park, NY 11729-4681
Phone (631) 586 7600 Fax (631) 242 9798 www.sensitron.com sales@sensitron.com
