Ordering number : ENA1447A
Bi-CMOS IC
LV762XXX
Series
Overview
For NTSC/PAL/SECAM Color TVs
Built-in CTV Microcontroller
Video and Sound Processing ICs
(VIF/SIF/Y/C/Deflection/CbCr IN)
The LV762XXX series is a single-chip video and sound processor IC with a built-in microcontroller that supports all of the
NTSC, PAL and SECAM broadcasting systems. The IC provides fully integrated solution to rationalize the design of color
TV sets, increase productivity, and reduce total costs.
Functions
•
I
2
C bus control system with a built-in microcontroller
•
VIF/SIF/Y/C/Deflection/CbCr IN
•
Adjustment-free VIF/SIF
•
1X’tal multi-system that supports NTSC, PAL and SECAM broadcasting systems
•
No VCO coil required
•
Internal sound carrier BPF, 4-system sound carrier trap
•
Digital AFT system
Any and all SANYO Semiconductor Co.,Ltd. products described or contained herein are, with regard to
"standard application", intended for the use as general electronics equipment (home appliances, AV equipment,
communication device, office equipment, industrial equipment etc.). The products mentioned herein shall not be
intended for use for any "special application" (medical equipment whose purpose is to sustain life, aerospace
instrument, nuclear control device, burning appliances, transportation machine, traffic signal system, safety
equipment etc.) that shall require extremely high level of reliability and can directly threaten human lives in case
of failure or malfunction of the product or may cause harm to human bodies, nor shall they grant any guarantee
thereof. If you should intend to use our products for applications outside the standard applications of our
customer who is considering such use and/or outside the scope of our intended standard applications, please
consult with us prior to the intended use. If there is no consultation or inquiry before the intended use, our
customer shall be solely responsible for the use.
Specifications of any and all SANYO Semiconductor Co.,Ltd. products described or contained herein stipulate
the performance, characteristics, and functions of the described products in the independent state, and are not
guarantees of the performance, characteristics, and functions of the described products as mounted in the
customer
'
s products or equipment. To verify symptoms and states that cannot be evaluated in an independent
device, the customer should always evaluate and test devices mounted in the customer
'
s products or
equipment.
52009 MS No.A1447-1/6
LV762XXX Series
Operating Conditions (BIP Chip)
at Ta = 25°C
Parameter
Recommended supply voltage
Symbol
V62
V4
Recommended supply current
I9
I20
I49
Operating supply voltage range
V62
V4
Operating supply current range
I9
I20
I49
Conditions
Ratings
5.0
5.0
11
13
22
4.7 to 5.3
4.7 to 5.3
9 to 13
11 to 15
20.5 to 26.5
Unit
V
V
mA
mA
mA
V
V
mA
mA
mA
Recommended Operating Range (Micro-computer Chip)
at Ta
=
-10°C to +65°C, VSS = 0V
Parameter
Operating supply
voltege
Hold voltage
High level input
voltage
VIH (2)
VIH (3)
Low level input
voltage
VIL (2)
VIL (3)
Operation cycle
time (*1)
tCYC (1)
tCYC (2)
FmVCO1
FmVCO1
(*2)
FmRC
FsX'tal
Oscillation
stabilizing time
tmsVCO
XT1 (P07)
XT2 (P06)
VIL (1)
VHD
VIH (1)
CpuVDD
Ports0, 1,
P00 port input
/interrupt
Port00
Watch-dog timer
RES
Ports0, 1,
P00 port input
/interrupt
Port00
Watch-dog timer
RES
All functions operating
OSD and Data slicer are not
operating
Oscillation
frequency range
Built-in VCO1
Oscillation System clock
Built-in VCO2
oscillation
OSD clock
Built-in RC oscillation
At the 32.768KHz crystal
Oscillating See the figure 1
•after
the HOLD mode
•Power-On
4.5 to 5.5
300
mS
4.5 to 5.5
4.5 to 5.5
0.3
1.0
32.768
2.0
MHz
kHz
OCKSEL = 0
OCKSEL = 1
4.5 to 5.5
12.5
16.6
MHz
MHz
4.5 to 5.5
13.0
MHz
4.5 to 5.5
4.5 to 5.5
4.5 to 5.5
0.231
VSS
0.231
200
4.5 to 5.5
VSS
0.15VDD
+0.4
0.25VDD
V
V
µs
µs
4.5 to 5.5
4.5 to 5.5
0.75VDD
VSS
VDD
0.1VDD
+0.4
V
V
4.5 to 5.5
0.9VDD
VDD
V
RAMs and the registers data are
kept in HOLD mode.
4.5 to 5.5
0.3VDD
+0.7
VDD
V
2.0
5.5
V
Symbol
VDD
Pins
CpuVDD
Conditions
0.229µs
≤
tCYC
≤
200µs
VDD [V]
Ratings
min
4.5
typ
max
5.5
V
Unit
(Note) FLASH-ROM erase/write temperature range : Ta = 25±2°C (VDD = 4.5 to 5.5V)
(*1) Relational expression between tCYC and oscillation frequency ;
1/1 frequency dividing : 3/FmVCO1, 1/2 frequency dividing : 6/FVCO1.
(*2) OCKSEL is the selectable register for OSD clock frequency. (See the LC873200 users manual for details.)
No.A1447-3/6
