8-163320-6

Description
CONNECTOR, 8 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, SOLDER, ROHS COMPLIANT
CategoryThe connector    The connector
File Size110KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

8-163320-6 Overview

CONNECTOR, 8 CONTACT(S), FEMALE, STRAIGHT SINGLE PART CARD EDGE CONN, SOLDER, ROHS COMPLIANT

8-163320-6 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
package instructionROHS COMPLIANT
Reach Compliance Codeunknow
Connector typeCARD EDGE CONNECTOR
Contact to complete cooperationNOT SPECIFIED
Contact point genderFEMALE
Contact materialPHOSPHOR BRONZE
DIN complianceNO
Filter functionNO
IEC complianceNO
MIL complianceNO
Manufacturer's serial number163320
Mixed contactsNO
Installation methodSTRAIGHT
Installation typeBOARD
Number of rows loaded2
OptionsGENERAL PURPOSE
Terminal pitch3.96 mm
Termination typeSOLDER
Total number of contacts8
Base Number Matches1
My Account
Tyco Electronics
(C hange)
Se a rch by Ke yword or Pa rt #
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
> .050 Inch C enterline
>
Product Feature Selector
> Product Details
8-163320-6 Product Details
Live Product Chat
AMP EDGE Connectors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
8-163320-6
T E I nternal N umber: 8 - 1 6 3 3 2 0 - 6
Product Highlights:
l
C onnector
l
3.96 mm C enterline
l
8 Positions
l
Number of Rows = Dual
l
Housing Style = Without Mounting Ears
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Number of Positions
= 8
l
Housing Style
= Without Mounting Ears
l
PC B Mount Angle
= Vertical
l
Post Type = Board to Board
l
PC B Thickness (mm [in]) = 1.60 [0.063]
l
Product Series = Type I
l
Keying Plug Material = Synthetic
l
Profile = Standard
Body Related Features:
l
C enterline (mm [in])
= 3.96 [0.156]
l
Number of Rows
= Dual
Contact Related Features:
l
C ontact Plating, Mating Area, Material
= Gold (30)
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Polycarbonate GF
l
Housing C olor = Green
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = AMP
