1-1623839-2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 1-1623839-2

1-1623839-2: DescriptionRESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.5W, 50000ohm, ROHS COMPLIANT; CategoryPassive components The resistor; File Size114KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric Compare View All

1-1623839-2 Overview

RESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.5W, 50000ohm, ROHS COMPLIANT

1-1623839-2 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	TE Connectivity
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
Actuator direction	HORIZONTAL
Actuator type	SCREW
Manufacturer's serial number	4295
Installation features	THROUGH HOLE MOUNT
Number of terminals	3
number of turns	1
Package shape	RECTANGULAR PACKAGE
Rated power dissipation(P)	0.5 W
resistance	50000 Ω
resistance law	LINEAR
Resistor type	TRIMMER
surface mount	NO
technology	CERMET
Terminal surface	NOT SPECIFIED
Terminal shape	WIRE
Tolerance	10%

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Resistors

Product Feature Selector

> Product Details

404806394012 Product Details

Live Product Chat

Variable Resistors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

404806394012

(1-1623839-2)

T E I nternal N umber: 1 - 1 6 2 3 8 3 9 - 2

Product Highlights:

Variable Resistor

Resistor Type = Trimmer

Resistance Selection = K ?

Resistance = 50K ?

Power Rating = .50 W

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

Professional Trimmers - Type 4295 Series - Tyco Elec...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Variable Resistor

Resistor Type

= Trimmer

Resistance (?)

= 50K

Element

= C ermet

Sealed

= Yes

Mount Angle

= Vertical

Termination Type

= PC B Terminations

Electrical Characteristics:

Resistance Selection (?) = K

Power Rating (W)

= 0.50

Tolerance (%)

= 10

Termination Related Features:

Termination Post Orientation

= In Line

Body Related Features:

Series

= 4295

Package, C omponent Size

= 10

Configuration Related Features:

Sections

= Single

Adjustment Location

= Side

Adjustment Style

= Screwdriver Slot

Operating Function

= Single Turn

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C , Wave

solder capable to 260?C , Wave solder capable to 265?C

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Conditions for Usage:

Temperature C oefficient (ppm/?C )

= 100

Other:

Brand = C itec

Additional Information:

Product Line Information

1-1623839-2 Related Products

	1-1623839-2	404806394012
Description	RESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.5W, 50000ohm, ROHS COMPLIANT	RESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.5W, 50000ohm, ROHS COMPLIANT
Maker	TE Connectivity	TE Connectivity
Reach Compliance Code	unknown	unknown
ECCN code	EAR99	EAR99
Actuator direction	HORIZONTAL	HORIZONTAL
Actuator type	SCREW	SCREW
Manufacturer's serial number	4295	4295
Installation features	THROUGH HOLE MOUNT	THROUGH HOLE MOUNT
Number of terminals	3	3
number of turns	1	1
Package shape	RECTANGULAR PACKAGE	RECTANGULAR PACKAGE
Rated power dissipation(P)	0.5 W	0.5 W
resistance	50000 Ω	50000 Ω
resistance law	LINEAR	LINEAR
Resistor type	TRIMMER	TRIMMER
surface mount	NO	NO
technology	CERMET	CERMET
Terminal shape	WIRE	WIRE
Tolerance	10%	10%
