8-1532126-7

Description
D MICROMINIATURE CONNECTOR
CategoryThe connector    The connector
File Size128KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric Compare View All

8-1532126-7 Overview

D MICROMINIATURE CONNECTOR

8-1532126-7 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
Objectid8000663517
Reach Compliance Codecompliant
Body/casing typeRECEPTACLE
Connector typeD MICROMINIATURE CONNECTOR
Contact to complete cooperationNOT SPECIFIED
Contact point genderFEMALE
Contact materialNOT SPECIFIED
contact modeSTAGGERED
insulator materialPOLYPHENYLENE SULPHIDE
Plug contact pitch0.1 inch
Installation option 1LOCKING
Installation methodSTRAIGHT
Installation typeBOARD
Number of rows loaded2
OptionsGENERAL PURPOSE
reliabilityCOMMERCIAL
Shell surfaceNICKEL
Housing sizeA
Termination typeSOLDER
Total number of contacts9

8-1532126-7 Preview

This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Pin & Socket Connectors > Product Feature Selector > Product Details
M83513/25­A03NP Product Details
Microminiature D Connectors
Not EU RoHS or ELV Compliant
 (
Find RoHS Compliant Alternates
)
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Product Highlights:
Connector
Connector Design = PCB Connector
Connector Style = Receptacle
Contact Type = Socket
Product Series = MCK (Full Metal)
M83513/25­A03NP
(8­1532126­7)
TE Internal Number: 8­1532126­7
View all Features
 Superseded
Contact Product Information Center
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Connector
Connector Design = PCB Connector
Product Series = MCK (Full Metal)
PCB Mounting Orientation = Straight
Mechanical Attachment:
Mounting Hardware = Jackpost Assembly
Termination Features:
Termination Post Length (mm [in]) = 4.37 [0.172]
Body Features:
Shell Plating = Nickel, Electroless
Contact Features:
Contact Type = Socket
Contact Style = Printed Circuit Board
Housing Features:
Connector Style = Receptacle
Housing Material = Polyphenylene Sulfide (PPS)
Configuration Features:
Number of Positions = 9
Industry Standards:
Government/Industry Qualification = Yes
Government/Industry Part Number = M83513/25­A03NP
RoHS/ELV Compliance = Not ELV/RoHS compliant
Lead Free Solder Processes = Not reviewed for lead free solder
process
Other:
Brand = Microdot
Comment = Also available in commercial grade.
Corporate Information
About TE
Investors
News Room
Supplier Portal
Careers
Terms & Conditions
Privacy Policy
AODA Accessibility Policy
AODA Multi­Year Accessibility
Plan
Quick Links
Distributor Inventory
Product Cross Reference
Documents & Drawings
Product Compliance Support Center
Site Map
Customer Support
Email or Chat With Us
Find a Phone Number
Knowledge Base
Manage Your Account
Keep Me Informed

© 2014 TE Connectivity Ltd. family of companies. All Rights Reserved
 Provide Website Feedback
More (Only the first 5 pages are displayed. Please Download Datasheet to view the full content.) >

8-1532126-7 Related Products

8-1532126-7 M83513/25-A03NP
Description D MICROMINIATURE CONNECTOR 9 CONTACT(S), FEMALE, D MICROMINIATURE CONNECTOR, SOLDER, RECEPTACLE
Is it Rohs certified? incompatible conform to
Reach Compliance Code compliant unknown
Body/casing type RECEPTACLE RECEPTACLE
Connector type D MICROMINIATURE CONNECTOR D MICROMINIATURE CONNECTOR
Contact to complete cooperation NOT SPECIFIED NOT SPECIFIED
Contact point gender FEMALE FEMALE
Contact material NOT SPECIFIED NOT SPECIFIED
contact mode STAGGERED STAGGERED
insulator material POLYPHENYLENE SULPHIDE POLYPHENYLENE SULFIDE
Plug contact pitch 0.1 inch 0.05 inch
Installation option 1 LOCKING #2-56
Installation method STRAIGHT STRAIGHT
Installation type BOARD BOARD
Number of rows loaded 2 2
Options GENERAL PURPOSE GENERAL PURPOSE
Shell surface NICKEL NICKEL
Housing size A A
Termination type SOLDER SOLDER
Total number of contacts 9 9
