CX6VSM CRYSTAL
18 kHz to 600 kHz
™
Ultra-Low Profile (1mm) Miniature Surface Mount
Quartz Crystal for Pierce Oscillators
DESCRIPTION
The CX6VSM quartz crystals are leadless devices designed
for surface mounting on printed circuit boards or hybrid
substrates and intended to be used in Pierce oscillators.They
are hermetically sealed in a rugged, miniature ceramic
package. They are manufactured using the STATEK-
developed photolithographic process, and are designed
utilizing the experience acquired by producing millions of
crystals for industrial, commercial, military and medical
applications. Maximum process temperature should not
exceed 260
O
C.
FEATURES
actual size
side view
Glass Lid Shown
PACKAGE DIMENSIONS
D
A
TOP
BOTTOM
Miniature tuning fork design
Ultra-low profile (1mm)
High shock resistance
Designed for low power applications
Compatible with hybrid or PC board packaging
Low aging
Full military testing available
Ideal for battery operated applications
Designed and manufactured in the USA
EQUIVALENT CIRCUIT
B
C
D
TYP.
DIM
A
B
C
D
DIM “C”
MAX
SM1
SM2
SM3
inches
0.265
0.103
-
0.050
mm
6.73
2.62
-
1.27
inches
0.280
0.114
0.060
MAX.
mm
7.11
2.90
1.52
see below
GLASS LID
inches
0.039
0.041
0.044
mm
0.99
1.04
1.12
CERAMIC LID
inches
0.053
0.055
0.058
mm
1.35
1.40
1.47
C
0
1
L
1
C
1
R
1
2
R
1
Motional Resistance L
1
Motional Inductance
C
1
Motional Capacitance C
0
Shunt Capacitance
SUGGESTED LAND PATTERN
0.070 (1.78)
CONVENTIONAL CMOS
PIERCE OSCILLATOR CIRCUIT
R
f
BUFFER
OSC
Freq (f
O
)
AMPLIFIER
0.120 (3.05)
R
A
C
G
inches (mm)
0.215 (5.46)
CX6
CX-6
C
D
10132 - Rev B
S
YS
ERT
T
E
M
C
IFIC
T
A
N
IO
RSG Electronic Components GmbH - Sprendlinger Landstr. 115 - 63069 Offenbach - Germany - www.rsg-electronic.de
IS
O
90
01
SPECIFICATIONS
FIGURE 1
CX6V TYPICAL MOTIONAL RESISTANCE (R
1
)
* Tighter frequency calibration available.
** Other turning point available.
*** Higher shock and vibration available.
(in 1000's)
Specifications are typical at 25
O
C unless otherwise noted.
Specifications are subject to change without notice.
Frequency Range
18 kHz to 600 kHz
Functional Mode
Tuning Fork (Flexure)
Standard Calibration Tolerance* (see table below)
Motional Resistance (R
1
)
See Figure 1
MAX: 18-25 kHz, 2x Typ
25-600 kHz, 2.5x Typ
Motional Capacitance (C
1
) Figure 2
Quality Factor (Q)
Figure 3
MIN is 0.25x Typ
Shunt Capacitance (C
0
)
1.4 pF
Drive Level
18-25 kHz 0.5
µW
MAX
25-600 kHz 1.0
µW
MAX
Turning Point (T
0
)**
Figure 4
Temperature Coefficient (k) -0.035 ppm/
0
C
2
Aging, first year
5 ppm MAX
Shock, survival**
1,500 g peak, 0.3 ms, 1/2 sine
Vibration, survival**
10 g RMS, 20-2,000 Hz random
Operating Temp. Range
-10
O
C to +70
O
C (Commercial)
-40
O
C to +85
O
C (Industrial)
-55
O
C to +125
O
C (Military)
Storage Temp. Range
-55
O
C to +125
O
C
Max Process Temperature 260
O
C for 20 sec.
300
200
100
50
R
1
(k )
20
10
5
2
18
50
100
200
600
Frequency (kHz)
FIGURE 2
CX6V TYPICAL MOTIONAL CAPACITANCE (C
1
)
5
C
1
(fF)
2
1.0
0.5
18
50
100
200
600
Frequency (kHz)
FIGURE 3
CX6V TYPICAL QUALITY FACTOR (Q)
300
200
100
50
CX6V Standard Calibration T
olerance at 25
O
C
20
18
50
100
200
600
Frequency Range (kHz)
18-74.9
30 ppm
(0.003%)
+
_
+
_
FIGURE 4
CX6V TYPICAL TURNING POINT TEMP (T
0
)
.
Frequency (kHz)
75-169.9
50 ppm
(0.003%)
+
_
+
_
170-249.9
+
_
250-600
+
_
100 ppm
(0.01%)
200 ppm
(0.02%)
200 ppm
(0.02%)
500 ppm
(0.05%)
100 ppm
(0.01%)
100 ppm
(0.01%)
+
_
+
_
+
_
1000 ppm
(0.1%)
+
_
1000 ppm
(0.1%)
+
_
2000 ppm
(0.2%)
+
_
5000 ppm
(0.5%)
+80
+70
+60
+50
+40
+30
+20
+10
0
-10
-20
T
O
(
O
C)
18
50
100
200
600
Load Capacitance (C
L
), Used to Calibrate CX6V
(other C
L
available)
Frequency (kHz)
Note: Frequency f at temperature T is related to frequency f
0
at
turning point temperature T
0
by:
f-f
0
2
=
k(T-T
0
)
Frequency Load
Range
Capacitance
(kHz)
(pF)
18-24.9
25-54.9
55-100.0
10
9
8
Frequency
Range
(kHz)
100.1-179.9
180-600
Load
Capacitance
(pF)
5
4
f
0
TERMINATIONS
HOW TO ORDER CX6VSM CRYSTALS
CX6V
S
C
SM1
32.768K ,
Frequency
K = kHz
Designation
SM1
SM2
SM3
Termination
Gold Plated
Solder Plated
Solder Dipped
100
Calibration
Tolerance
@ 25
O
C
(in ppm)
/
M
PACKAGING OPTIONS
Blank = Glass Lid
C = Ceramic Lid
“S” if special or
custom design.
Blank if Srd.
SM1 = Gold Plated
SM2 = Solder Plated
SM3 = Solder Dipped
Operating Temp. Range:
C = -10
O
C to +70
O
C
I = -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
CX6VSM
- Tray Pack
-16mm tape, 7” or 13” reels
(Reference tape and reel data sheet 10109)
