AZ943H
15 AMP
MINIATURE
PC BOARD RELAY
FEATURES
•
•
•
•
•
•
•
High performance
Low seated height
4.5 kV surge withstand
Flux tight and sealed versions available
Class B insulation (130°C) standard
Class F insulation (155°C) available
UL, CUR File E43203
GENERAL DATA
Life Expectancy
Mechanical
Electrical
1 x 10
7
1 x 10
5
at 10 A 277 VAC Res.
10 ms max.
5 ms max.
(with no coil suppression)
CONTACTS
Arrangement
Ratings
SPST (1 Form A)
SPDT (1 Form C)
Form A and C
Max. switched power: 210 W or 2770 VA
Max. switched current: 15 A AC, 7 A DC
Max. switched voltage: 30 VDC or 300 VAC
1 Form A
15 A at 125 VAC, general use
10A at 277 VAC, general use, 100,000 cycles
TV - 5 120 VAC
1/2 HP at 125 VAC
125 VA at 120 VAC Pilot Duty, 100k cycles (N.O.)
1 Form C
10 A at 277 VAC, general use, 100,000 cycles
1/2 HP at 125 VAC N.O.
125 VA at 120 VAC Pilot Duty, 100k cycles (N.O.)
10 A/7A N.O./N.C. at 30 VDC resistive
Material
Resistance
Silver tin oxide (gold plating available)
Operate Time
Release Time
Dielectric Strength
2500 Vrms contact to coil
(at sea level for 1 min.)
1000 Vrms across contacts
Insulation Resistance
Dropout
Ambient Temperature
Operating
Storage
Vibration
Shock
Enclosure
100 megohms min. at 500 VDC,
50% RH
Greater than 10% of nominal coil voltage
At nominal coil voltage
-40°C(-40°F) to 90°C(194°F) Class B
-40°C(-40°F) to 110°C(230°F) Class F
-40°C(-40°F) to 130°C(266°F)
0.062" DA at 10–55 Hz
10 g
P.B.T. polyester
Tinned copper alloy, P.C.
270°C (518°F)
5 seconds
80°C (176°F)
30 seconds
10 g
UL/CUR
< 100 milliohms initially
(24 V, 1 A method)
Terminals
Max. Solder Temp.
Max. Solder Time
COIL
Power
At Pickup Voltage
Max Continuous
Dissipation
Temperature Rise
Temperature
203 mW
1.8 W at 20°C (68°F) Class B
2.4 W at 20°C (68°F) Class F
32°C (58°F) at nominal coil voltage
Max. 130°C (266°F) Class B
Max. 155°C (311°F) Class F
Max. Solvent Temp.
Max. Immersion Time
Weight
NOTES
1. All values at 20°C (68°F).
2. Relay may pull in with less than “Must Operate” value.
3. Unsealed relays should not be dip cleaned.
4. Specifications subject to change without notice.
12/22/08
