AZ956P
AZ
MICROMINIATURE
POLARIZED BISTABLE
(LATCHING) RELAY
FEATURES
•
Microminiature size: up to 50% less board area than
previous generation telecom relays
•
Meets FCC Part 68.302 1500 V lightning surge
•
High dielectric and surge voltage:
•
Low power consumption: 36 mW pickup
•
Stable contact resistance for low level signal switching
•
Epoxy sealed for automatic wave soldering and cleaning
•
UL, CUR file E43203
•
All plastics meet UL94 V–0, 30 min. oxygen index
GENERAL DATA
Life Expectancy
Mechanical
Electrical
Minimum operations
1 x 10
9
2.5 x 10
5
at 0.4 A, 125 VAC, resistive
3 x 10
6
at 1.0 A, 24 VDC, resistive
1 ms at nominal coil voltage
0.9 ms at nominal coil voltage
At 10 mA contact current
1 ms at set or reset
1500 Vrms contact to coil
500 Vrms between open contacts
10
9
ohms min. at 25°C, 500 VDC,
50% RH
At nominal coil voltage
-40°C (-40°F) to 70°C (158°F)
-40°C (-40°F) to 105°C (221°F)
Operational, 40 g, 10–200 Hz
Operational, 50 g min., 11 ms
Non-destructive, 150 g min., 11 ms
Vapor phase: 215°C, 40 Sec.
Infrared: 215°C, 40 Sec.
Double wave: 260°C, 10 Sec.
80°C (176°F)
30 seconds
1.8 grams
P.B.T. polyester
Tinned copper alloy, P.C.
CONTACTS
Arrangement
Ratings
SPDT (1 Form C)
Bifurcated crossbar contacts
Resistive load:
Max. switched power: 30 W or 60 VA
Max. switched current: 1.0 A
Max. switched voltage: 150 VDC or 125 VAC
Rated Load
UL
Material
Resistance
0.5 A at 120 VAC
1.0 A at 30 VDC
Palladium nickel with gold-rhodium overlay
< 50 milliohms initally
(6 V, 10 mA method)
Set Time
(typical)
Reset Time (typical)
Bounce (typical)
Dielectric Strength
(at sea level)
Insulation Resistance
Ambient Temperature
Operating
Storage
Vibration
COIL (Polarized)
Power
At Pickup Voltage
(typical)
Max. Continuous
Dissipation
Temperature Rise
Temperature
36 mW
0.5 W at 20°C (68°F)
At nominal coil voltage
8°C (15°F)
Max. 105°C (221°F)
Shock
Max. Solder Temp.
Temp./Time
Max. Solvent Temp.
Max. Immersion Time
Weight
Enclosure
Terminals
NOTES
1. All values at 20°C (68°F).
2. Relay may set or reset in with less than “Must Operate” value.
3. Relay has fixed coil polarity.
4. Specifications subject to change without notice.
7/24/02W
AZ956P
AZ
RELAY ORDERING DATA
STANDARD SINGLE COIL
Nominal Coil
VDC
1.5
3
5
9
12
15
24
Nominal Coil
VDC
1.5
3
5
9
12
15
Max. Operating
VDC
6
13
20
35
50
50
50
Max. Operating
VDC
4.25
8.55
14.75
25.6
29
29
Coil Resistance
± 10%
61
300
740
2160
4500
4500
4500
Coil Resistance
± 10%
32
130
390
1200
1500
1500
Must Operate
VDC
1.13
2.25
3.75
6.75
9.00
11.3
18.00
Must Operate
VDC
1.13
2.25
3.75
6.75
9.00
11.3
Order Number
THT
SMT
Through Hole
AZ956P1–1.5DE AZ956P1S–1.5DE
AZ956P1–3DE
AZ956P1–5DE
AZ956P1S–3DE
AZ956P1S–5DE
AZ956P1–9DE
AZ956P1S–9DE
AZ956P1–12DE AZ956P1S–12DE
AZ956P1–15DE AZ956P1S–15DE
AZ956P1–24DE AZ956P1S–24DE
STANDARD DUAL COIL
Order Number
THT
SMT
Through Hole
AZ956P2–1.5DE AZ956P2S–1.5DE
AZ956P2–3DE
AZ956P2–5DE
AZ956P2S–3DE
AZ956P2S–5DE
AZ956P2–9DE
AZ956P2S–9DE
AZ956P2–12DE AZ956P2S–12DE
AZ956P2–15DE AZ956P2S–15DE
MECHANICAL DATA
THT
SMT
.006
(.15)
.08 MAX
(2)
PC BOARD LAYOUT
Viewed toward terminals
PC BOARD LAYOUT
Viewed toward terminals
Wiring Diagram
Viewed toward terminals
Single Coil Latching
Shown in reset Position
Dual Coil Latching
Shown in reset position
Dimensions in inches with metric equivalents in parentheses. Tolerance: ± .010"
7/24/02W
