1206SFS550F/242 Product Details
Fuses
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
Type = DC Slow Blow Fuse
Surface Mount Construction
Form Factor (inches) = 1206
Form Factor (mm) = 3216
Rated Current = 5.5 A
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
1206SFS550F/242
TE Internal Number: A52099000
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
CP CATALOG 2011FUSES (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Family Name = SFS
Electrical Characteristics:
Rated Current (A) = 5.5
Cold DCR (Nominal) (Ω) = 0.014
I²t (A²sec)² (Nominal) (Ω) = 6.4
Interrupt Voltage, Max. (VDC) = 24
Interrupt Current, Max. (A) = 50
Termination Features:
Construction = Surface Mount
Body Features:
Type = DC Slow Blow Fuse
Configuration Features:
Form Factor (inches) = 1206
Form Factor (mm) = 3216
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Reflow solder capable to 245°C,
Reflow solder capable to 260°C
RoHS/ELV Compliance History = Always was RoHS compliant
UL Listed = File No. E197536
Environmental:
Operating Temperature (Max.) (°C) = 125
Conditions for Usage:
Min Clear Time @ 100% Rated Current (Hr) = 4
Min Clear Time @ 200% Rated Current (Seconds) = 1
Min Clear Time @ 300% Rated Current (Seconds) = 0.1
Min Clear Time @ 800% Rated Current (Seconds) = 0.002
Other:
Brand = Raychem
