Specification Control Drawing
100G0121
Issue 6
26th November 2012
Page 1 of 1
TWO CONDUCTOR CABLE, HALOGEN FREE, THIN WALL
750/1300 VOLT AC, 125°C
The complete requirements for procuring the wire described herein shall consist of this document.
Component wire -
100G0111
Part
Description
100G0121-0.15-*/*
100G0121-0.25-*/*
100G0121-0.40-*/*
100G0121-0.50-*/*
100G0121-0.60-*/*
100G0121-0.75-*/*
100G0121-1.00-*/*
100G0121-1.20-*/*
100G0121-1.50-*/*
100G0121-2.00-*/*
100G0121-2.50-*/*
100G0121-3.00-*/*
100G0121-4.00-*/*
Nominal
Outside Diameter
Cross Equivalent
(mm)
Sectional
AWG
Size
Area
(mm²)
Nom
Max
26
0.15
2.06
2.16
24
0.25
2.29
2.39
22
0.40
2.66
2.77
-
0.50
2.82
2.90
20
0.60
3.04
3.14
-
0.75
3.24
3.29
18
1.00
3.49
3.59
16
1.20
3.86
3.96
15
1.50
4.16
4.26
14
2.00
4.72
4.82
13
2.50
5.13
5.26
12
3.00
5.56
5.71
-
4.00
6.18
6.33
Maximum
Weight
(kg/km)
5.34
7.40
10.7
13.6
15.2
18.3
22.0
28.0
33.0
41.8
52.9
63.9
89.8
COLOUR CODE:
The '*' in the part description shall be replaced by a standard colour code designator in
accordance with Mil Std 681.
e.g. 100G0121-1.00-2/6 cores red and blue insulations.
PERFORMANCE
REQUIREMENTS:
Primary wires shall meet the requirements of the issue in effect of WSD912.
Lay Length shall be Left Hand and 12 ± 4 times the Nom.Outer Diameter indicated above
Jacket Flaws to be tested with a spark test of 8 kV Impulse (peak).
This product will be available in the full colour range and may be marked or unmarked in accordance with the order.
APPROVAL:
Tyco Electronics UK Ltd
Faraday Road
Dorcan
SWINDON
SN3 5HH
Tel: +44 (0)1793 528171
Fax: +44 (0)1793 572516
Electronic sign off - no signatures will appear.
TE Connectivity is aatrading name of Tyco
TE Connectivity is trading name of Tyco
Electronics UK Ltd, which is registered in
Electronics UK Ltd, which is registered in
England and Wales, number 550926.
England and Wales, number 550926.
Registered office: Faraday Road, Dorcan,
Registered office: Faraday Road, Dorcan,
Swindon, SN3 5HH
Swindon, SN3 5HH
Website:
Website:
www.te.com
This drawing and the information set forth hereon are the property of Tyco
Electronics UK Ltd, and are to be held in trust and confidence. Publication,
duplication, disclosure or use for any purpose not expressly authorised in
writing by Tyco Electronics UK Ltd is prohibited.
This specification sheet takes precedence over documents referenced
herein. As Tyco Electronics UK Ltd. reserve the right to make changes
in construction without notice please contact Tyco Electronics UK Ltd to
ensure that this document is the latest issue.
©2012 Tyco Electronics UK Ltd, a TE Connectivity Ltd. company. All Rights Reserved.
