VOLTAGE CONTROLLED
OSCILLATOR
2000 - 2500 MHz
TOM9250
Features
!
!
!
!
Low Noise Bipolar Transistor
Broad Tuning Range
Operating Case Temp. -55 ºC to + 85 ºC
Environmental Screening available
Available as:
TOM9250, 4 Pin TO-8 (T4)
TON9250, 4 Pin Surface Mount (SM3)
TOP9250, 4 Pin Flatpack (FP4)
BXO9250, Connectorized Housing (H1)
Specifications
CHARACTERISTIC
5Frequency
Output Power (dBm)
Power Flatness (dB)
Tuning Voltage Range (v)
Tuning Voltage
Sensitivity (MHz/V)
Harmonics (dBc)
Spurious (dBc)
3dB Modulation BW
Zg = 50 Ohm
Pushing (MHz/V)
Pulling (MHz); 20 dB RL
Frequency Drift (MHz/ºC
Power
Vdc
mA
Maximum Ratings
TYPICAL
Ta = 25 ºC
2000 - 2500 MHz
+11.5
±0.75
1 to 14
40
-20
<-80
--
4
25
0.10
+15
30
MIN/MAX
Ta = -55 ºC to +85 ºC
2000 - 2500 MHz
+9.0 Min.
±1.5 Max.
1 to 15
15 Min.
-12 Max.
<-60 Max.
20 MHz Min.
9 Max.
35 Max.
0.15 Max.
+15
40 Max.
Ambient Operating Temperature ....................... -55ºC to + 100 ºC
Storage Temperature ........................................ -62ºC to + 125 ºC
Case Temperature ........................................................... + 125 ºC
DC Voltage .................................................................... + 20 Volts
Maximum DC Tuning Voltage ......................................... + 20 Volts
Minimum DC Tuning Voltage ................................................. 0 Volt
Typical Performance Data
+15.0
Output Power
(dBm)
+13.0
+11.0
+ 9.0
1
4
7
10
13
16
Tuning Voltage (Volts)
2700
Frequency
(MHz)
2500
2300
2100
1900
1700
1
4
7
10
13
16
Tuning Voltage (Volts)
Legend ------------- + 25 ºC -- -- -- +85 ºC - - - - - - -55 ºC
Notes:
1. Phase Noise is measured using the Aeroflex PN9000.
2. Worst case phase noise @ 100KHz offset across
frequency range and temperature extremes is -100 dBc/Hz.
Spectrum Microwave · 2144 Franklin Drive N.E. · Palm Bay, Florida 32905 · PH (888) 553-7531 · Fax (888) 553-7532
Rev. C
04/11/02
www.SpectrumMicrowave.com
Spectrum Microwave (Europe) · 2707 Black Lake Place · Philadelphia, Pa. 19154 · PH (215) 464-4000 · Fax (215) 464-4001
