RF AMPLIFIER
MODEL
TR7216
Features
!
Low Noise Figure: <2.5 dB Typical
!
High 3rd Order Intercept: >+33 dBm Typical
Available as:
TR7216, 4 Pin TO-8B (T8)
RN7216, 4 Pin Surface Mount (SM19)
BR7216, Connectorized Housing (H2)
Typical Intermodulation Performance at 25 º C
Second Order Harmonic Intercept Point....... +49 dBm (Typ.)
Second Order Two Tone Intercept Point........ +44 dBm (Typ.)
Third Order Two Tone Intercept Point............ +33 dBm (Typ.)
Specifications
CHARACTERISTIC
Frequency
Gain (dB)
Power @ 1 dB
Comp. (dBm)
Reverse
Isolation (dB)
VSWR
In
Out
TYPICAL
Ta= 25 ºC
10-500 MHz
25.5
+20
-32
<1.75:1
<1.5:1
<2.5
+12
65
MIN/MAX
Ta = -55 ºC to +85 ºC
10-500 MHz
24.0 Min.
+18.0 Min.
-30 Max.
2.0:1 Max.
2.0:1 Max.
3.0 Max.
+12 Min.
70 Max.
Maximum Ratings
Ambient Operating Temperature .............. -55ºC to + 100 ºC
Storage Temperature ............................... -62ºC to + 125 ºC
Case Temperature ................................................. + 125 ºC
DC Voltage ......................................................... + 18 Volts
Continuous RF Input Power ................................. + 20 dBm
Short Term RF Input Power .... 200 Milliwatts (1 Minute Max.)
Maximum Peak Power .................... 0.5 Watt (3
µsec
Max.)
Noise Figure (dB)
Power
Vdc
mA
Note: Care should always be taken to effectively ground the case of each unit.
Typical Performance Data
27
26
25
24
23
Start 10 MHz
Stop 500 MHz
Gain (dB)
0
- 10
- 20
- 30
- 40
Reverse Isolation (dB)
3
2
1
Start 10 MHz
Stop 500 MHz
Start 10 MHz
Noise Figure (dB)
Stop 50
+22
+21
+20
+19
+18
Start 10 MHz
1 dB Comp. (dBm)
2.0
1.5
1.0
Stop 500 MHz
Start 10 MHz
Input VSWR
2.0
1.5
1.0
Stop 500 MHz
Start 10 MHz
Output VSWR
Stop 50
Legend
+ 25 ºC
Linear S-Parameters
+ 85 ºC - - - - - - -55 ºC
FREQ.
– – – – S11– – – –
– – – – S21– – – –
– – – – S12– – – –
– – – – S22– – – –
MHz
Mag
Deg
Mag
Deg
Mag
Deg
Mag
Deg
=========================================================================================================
10
.16
- 29
20.16
9
.01
1
-137
.09
20
.14
- 29
20.14
- 4
.01
- 4
-162
.08
50
.14
- 43
19.77
- 26
.01
- 30
171
.08
100
.15
- 69
19.35
- 55
.01
- 69
145
.06
200
.19
-115
18.91
-110
.01
-123
149
.05
300
.21
-154
18.60
-166
.02
173
127
.10
400
.24
173
18.70
135
.03
135
77
.17
500
.31
135
18.02
72
.03
88
23
.20
Spectrum Microwave · 2144 Franklin Drive N.E. · Palm Bay, Florida 32905 · PH (888) 553-7531 · Fax (888) 553-7532
7/7/04
www.spectrummicrowave.com
Spectrum Microwave (Europe) · 2707 Black Lake Place · Philadelphia, Pa. 19154 · PH (215) 464-4000 · Fax (215) 464-4001
