Tension spring |
Spacing 5.0 mm
AK3001/..KD-5.0-PEBBLE GREY
1- to n-poles
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.08 mm²
2.5 mm²
0.14 mm²
2.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 5.0 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
12.90
17.90
22.90
27.90
32.90
37.90
42.90
47.90
52.90
57.90
62.90
67.90
72.90
77.90
82.90
87.90
92.90
97.90
102.90
107.90
112.90
117.90
122.90
Article Designation
AK3001/2KD-5.0-PEBBLE GREY
AK3001/3KD-5.0-PEBBLE GREY
AK3001/4KD-5.0-PEBBLE GREY
AK3001/5KD-5.0-PEBBLE GREY
AK3001/6KD-5.0-PEBBLE GREY
AK3001/7KD-5.0-PEBBLE GREY
AK3001/8KD-5.0-PEBBLE GREY
AK3001/9KD-5.0-PEBBLE GREY
AK3001/10KD-5.0-PEBBLE GREY
AK3001/11KD-5.0-PEBBLE GREY
AK3001/12KD-5.0-PEBBLE GREY
AK3001/13KD-5.0-PEBBLE GREY
AK3001/14KD-5.0-PEBBLE GREY
AK3001/15KD-5.0-PEBBLE GREY
AK3001/16KD-5.0-PEBBLE GREY
AK3001/17KD-5.0-PEBBLE GREY
AK3001/18KD-5.0-PEBBLE GREY
AK3001/19KD-5.0-PEBBLE GREY
AK3001/20KD-5.0-PEBBLE GREY
AK3001/21KD-5.0-PEBBLE GREY
AK3001/22KD-5.0-PEBBLE GREY
AK3001/23KD-5.0-PEBBLE GREY
AK3001/24KD-5.0-PEBBLE GREY
Article Number
53001020001F
53001030001F
53001040001F
53001050001E
53001060001E
53001070001E
53001080001D
53001090001D
53001100001D
53001110001D
53001120001D
53001130001D
53001140001D
53001150001D
53001160001D
53001170001D
53001180001D
53001190001D
53001200001D
53001210001D
53001220001D
53001230001D
53001240001D
PU
200
200
200
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule 0.14 mm²
min
Stranded with Ferrule 1.5 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Solder Tag
Tension Spring
Copper Alloy
Stainless Steel
6.0 mm
1.0 mm
Colours
PEBBLE GREY
ORANGE
BLUE
LIGHT GREEN
21
RAL7032
RAL2011
RAL5015
similar RAL 6018
RAL7032
22
23
24
RAL2011
RAL5015
similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Accessories
Figure
Designation
Bridge, 2-pole, insulated, BRI/2-5.0/5.08-
LIGHT GREY
Article Number
50000000006
Bridge, 3-pole, insulated, BRI/3-5.0/5.08-
LIGHT GREY
50000000007
Bridge, 2-pole, BR/2-5.0/5.08-L7.0
50000000008
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Test Voltage
B
300 V
15 A
AWG 28-14
AWG 28-14
1.6 kV
C
-
-
-
-
-
D
300 V
10 A
AWG 28-14
AWG 28-14
1.6 kV
min
0.5 mm²
0.5 mm²
250 V
24 A
max
2.5 mm²
2.5 mm²
2.0 kV
