Coaxial
Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
10W max.
0.125W max.
ZN2PD-1900+
ZN2PD-1900
50Ω
1600 to 1900 MHz
Features
• low insertion loss, 0.18 dB typ.
• high isolation, 30 dB typ.
• up to 10W power input as a splitter
• excellent amplitude unbalance, 0.1 dB typ.
• excellent VSWR, 1.1:1 typ.
• rugged shielded case
CASE STYLE: VVV180
Connectors Model
SMA
ZN2PD-1900(+)
Price
$69.95
Qty.
(1-9)
Coaxial Connections
SUM PORT
PORT 1
PORT 2
S
1
2
Applications
• PCS/DCS
• GPS
• communications systems
• instrumentations
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Electrical Specifications
Outline Drawing
FREQ.
RANGE
(MHz)
ISOLATION
(dB)
AMPLITUDE
INSERTION LOSS (dB)
PHASE
ABOVE 3.0 dB
UNBALANCE UNBALANCE
(dB)
(Degrees)
S
f
L
-f
U
1600-1900
Typ. Min.
30
20
Typ. Max.
0.18
0.4
Max.
2
Max.
0.2
Typ. Max.
1.2 1.35
VSWR
(:1)
OUT
Typ. Max.
1.04 1.20
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
1600.00
1610.00
1633.33
1656.66
1680.00
3.17
3.16
3.16
3.15
3.17
3.16
3.15
3.17
3.16
3.15
3.16
3.17
3.19
3.17
3.19
ZN2PD-1900
INSERTION LOSS
3.4
INSERTION LOSS (dB)
S-1(dB)
S-2(dB)
Amplitude
Unbalance
(dB)
0.00
0.01
0.00
0.00
0.00
0.01
0.00
0.00
0.01
0.00
0.00
0.00
0.00
0.00
0.00
Isolation
(dB)
VSWR
S
VSWR
1
VSWR
2
S-2
3.17
3.17
3.17
3.15
3.17
3.16
3.15
3.17
3.17
3.16
3.16
3.17
3.19
3.17
3.19
26.50
27.17
28.56
30.38
32.40
34.40
35.76
35.15
34.54
32.60
30.37
28.61
27.10
25.75
24.47
1.17
1.16
1.14
1.12
1.10
1.09
1.07
1.05
1.04
1.03
1.01
1.02
1.03
1.05
1.07
ZN2PD-1900
ISOLATION
1.09
1.09
1.09
1.09
1.09
1.09
1.09
1.08
1.08
1.08
1.08
1.08
1.09
1.09
1.09
1.07
1.07
1.07
1.07
1.07
1.07
1.07
1.07
1.07
1.07
1.07
1.07
1.07
1.07
1.07
Outline Dimensions (
A
B
C
1.80
1.75
.66
45.72 44.45 16.76
H
1.625
41.28
D
E
.125 1.675
3.18 42.55
inch
mm
)
G
.125
3.18
wt
grams
34
F
.125
3.18
1703.33
1726.66
1750.00
1760.00
1783.33
1806.66
1830.00
1853.33
1876.66
1900.00
J
K
L
M
.31
.63
1.13
.88
7.87 16.00 28.70 22.35
50
45
ISOLATION (dB)
1650
1700
1750
1800
1850
1900
3.3
3.2
3.1
3.0
1600
40
35
30
25
20
15
1600
1650
1700
1750
1800
1850
1900
FREQUENCY (MHz)
FREQUENCY (MHz)
ZN2PD-1900
VSWR
1.20
#S-VSWR
1.15
VSWR
1.10
1.05
1.00
1600
#1-VSWR
#2-VSWR
electrical schematic
1650
1700
1750
1800
1850
1900
FREQUENCY (MHz)
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
EW
ALL N
minicircuits.com
REV. A
M106921
ZN2PD-1900
HY/TD/CP/AM
080610
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
The Design Engineers Search Engine
Provides ACTUAL Data Instantly From MINI-CIRCUITS At:
www.minicircuits.com
