Coaxial
Power Splitter/Combiner
2 Way-0°
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
5W max.
0.725W max.
ZN2PD-20+
50Ω
750 to 2000 MHz
Features
• wideband, 750 to 2000 MHz
• low insertion loss, 0.2 dB typ.
• good isolation, 23 dB typ.
• very good input VSWR, 1.18:1 typ.
• excellent output VSWR, 1.07:1 typ.
• up to 5W power input
CASE STYLE: VVV180
Connectors Model
SMA
ZN2PD-20-S+
Price
$67.95
Qty.
(1-9)
Coaxial Connections
SUM PORT
PORT 1
PORT 2
S
1
2
Applications
• VSAT
• communications systems
• instrumentations
FREQ.
RANGE
(MHz)
L
f
L
-f
U
750-2000
Typ. Min.
18
15
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
Electrical Specifications
ISOLATION
(dB)
M
Typ. Min.
25
20
U
Typ. Min.
18
15
Typ. Max.
0.2
0.5
Max.
4
Max.
0.3
Outline Drawing
AMPLITUDE
PHASE
INSERTION LOSS
UNBALANCE UNBALANCE
(dB)
(dB)
(Degrees)
ABOVE 3.0 dB
S
VSWR
(:1)
OUT
Typ. Max.
1.10 1.35
Typ. Max.
1.16 1.5
L = 750-875 MHz
M = 875-1850 MHz
U = 1850-2000 MHz
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
750.00
770.00
790.00
815.00
860.00
900.00
937.50
975.00
1170.00
1510.00
1850.00
1895.00
1940.00
1970.00
2000.00
3.23
3.08
3.21
3.24
3.07
3.23
3.20
3.14
3.21
3.19
3.16
3.20
3.18
3.21
3.21
Amplitude
Unbalance
(dB)
0.01
0.01
0.01
0.00
0.01
0.01
0.02
0.01
0.02
0.01
0.02
0.01
0.01
0.00
0.01
Isolation
(dB)
Phase
Unbalance
(deg.)
0.01
0.08
0.12
0.14
0.02
0.02
0.04
0.09
0.05
0.20
0.20
0.25
0.23
0.20
0.24
VSWR
S
VSWR
1
VSWR
2
S-2
3.22
3.07
3.20
3.24
3.06
3.22
3.18
3.13
3.19
3.18
3.14
3.21
3.17
3.21
3.20
17.70
18.24
18.90
19.76
21.37
23.15
24.86
26.62
27.51
23.31
21.74
20.63
19.32
18.54
17.80
1.37
1.35
1.33
1.31
1.28
1.26
1.23
1.22
1.18
1.17
1.05
1.06
1.10
1.12
1.15
ZN2PD-20+
ISOLATION
1.09
1.09
1.10
1.10
1.11
1.12
1.12
1.12
1.10
1.04
1.11
1.11
1.11
1.11
1.10
1.08
1.08
1.09
1.09
1.10
1.11
1.11
1.11
1.09
1.06
1.11
1.11
1.11
1.11
1.11
Outline Dimensions (
inch
)
mm
A
B
C
1.80
1.75
.66
45.72 44.45 16.76
H
1.625
41.28
D
E
.125 1.675
3.18 42.55
F
.125
3.18
G
.125
3.18
wt
grams
34
INSERTION LOSS (dB)
J
K
L
M
.31
.63
1.13
.88
7.87 16.00 28.70 22.35
ZN2PD-20+
INSERTION LOSS
3.5
S-1(dB)
S-2(dB)
35
ISOLATION (dB)
1000
1250
1500
1750
2000
3.4
3.3
3.2
3.1
3.0
750
30
25
20
15
10
750
1000
1250
1500
1750
2000
FREQUENCY (MHz)
FREQUENCY (MHz)
ZN2PD-20+
VSWR
1.5
#S-VSWR
#1-VSWR
#2-VSWR
electrical schematic
1.4
VSWR
1.3
1.2
1.1
1.0
750
1000
1250
1500
FREQUENCY (MHz)
1750
2000
EW
ALL N
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
minicircuits.com
REV. D
M108294
ZN2PD-20+
LC/TD/CP/AM
070610
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661 For detailed performance specs & shopping online see Mini-Circuits web site
