Rugged PCB type
Ordering information
LDA30F
R
LDA
1
2
30
3
F
4
-5
5
-O
1Series
name
2Output
wattage
3Universal
input
4Output
voltage
5Optional
C :with Coating
G :Low leakage current
S :with Chassis
SN :with Chassis & cover
Y :with Potentiometer
Recommended Noise Filter
NAC-06-472
High voltage pulse noise type : NAP series
Low leakage current type : NAM series
*The
Noise Filter is recommended
*to
connect with several devices.
MODEL
MAX OUTPUT WATTAGE[W]
DC OUTPUT
LDA30F-3
18
3V 6.0A
LDA30F-5
30
5V 6.0A
LDA30F-12
30
12V 2.5A
LDA30F-15
30
15V 2.0A
LDA30F-24
31.2
24V 1.3A
SPECIFICATIONS
LDA30F-3
LDA30F-5
LDA30F-12
LDA30F-15
LDA30F-24
AC85 - 264 1
f
or DC110 - 370
ACIN 100V
0.8typ (Io=100%)
CURRENT[A]
ACIN 200V
0.4typ (Io=100%)
FREQUENCY[Hz]
47 - 440 or DC
EFFICIENCY[%]
70typ
75typ
77typ
78typ
79typ
ACIN 100V
15typ (Io=100%) (At cold start)
INRUSH CURRENT[A]
ACIN 200V
30typ (Io=100%) (At cold start)
LEAKAGE CURRENT[mA]
0.75max (60Hz, According to UL, CSA, VDE and DEN-AN)
VOLTAGE[V]
3
5
12
15
24
CURRENT[A]
6
6
2.5
2
1.3
LINE REGULATION[mV]
20max
20max
48max
60max
96max
LOAD REGULATION[mV]
40max
40max
100max
120max
150max
0 to +50
C
80max
80max
120max
120max
120max
RIPPLE[mVp-p]
-10 - 0
C
140max
140max
160max
160max
160max
0 to +50
C
120max
120max
150max
150max
150max
RIPPLE NOISE[mVp-p]
-10 - 0
C
160max
160max
180max
180max
180max
TEMPERATURE REGULATION[mV]
60max
60max
150max
180max
290max
*
1
20max
DRIFT[mV]
20max
48max
60max
96max
START-UP TIME[ms]
200max (ACIN 100V, Io=100%)
HOLD-UP TIME[ms]
10typ (ACIN 85V, Io=100%) 20typ (ACIN 100V, Io=100%)
OUTPUT VOLTAGE ADJUSTMENT RANGE[V]
2.85 - 3.6
Fixed ("Y"which can be adjusted the output is available as option :5, 12, 15, 24V
t
10%)
OUTPUT VOLTAGE SETTING[V]
xx
4.9 - 5.3
11.5 - 12.5
14.4 - 15.6
23.0 - 25.0
OVERCURRENT PROTECTION
Works over 105% of rating and recovers automatically
OVERVOLTAGE PROTECTION
4.00 - 5.25V
Works at 115 - 140% of rating
OPERATING INDICATION
Not provided
REMOTE SENSING
Not provided
REMOTE ON/OFF
Not provided
INPUT-OUTPUT
AC3,000V 1minute, Cutoff current = 10mA, DC500V 50M
W
min (At Room Temperature)
INPUT-FG
AC2,000V 1minute, Cutoff current = 10mA, DC500V 50M
W
min (At Room Temperature)
OUTPUT-FG
AC500V 1minute, Cutoff current = 100mA, DC500V 50M
W
min (At Room Temperature)
OPERATING TEMP.,HUMID.AND ALTITUDE
-10 to +60
C
, 20 - 90%RH (Non condensing) (Refer to DERATING CURVE) 3,000m (10,000feet) max
STORAGE TEMP.,HUMID.AND ALTITUDE
-20 to +75
C
, 20 - 90%RH (Non condensing) 9,000m (30,000feet) max
VIBRATION
10 - 55Hz, 19.6m/s
2
(2G), 3minutes period, 60minutes each along X, Y and Z axis
IMPACT
196.1m/s
2
(20G), 11ms, once each X, Y and Z axis
AGENCY APPROVALS
UL60950-1, EN60950-1, EN50178, CSA C22.2 No.234 Complies with DEN-AN and IEC60950-1
CONDUCTED NOISE
Complies with FCC-B, CISPR22-B, EN55022-B, VCCI-B
CASE SIZE/WEIGHT
55
X
26
X
133mm (W
X
H
X
D) /200g max (without chassis and cover)
COOLING METHOD
Convection
MODEL
VOLTAGE[V]
LDA
INPUT
OUTPUT
PROTECTION
CIRCUIT AND
OTHERS
ISOLATION
ENVIRONMENT
SAFETY AND
NOISE
REGULATIONS
OTHERS
*1
*
*
*
Drift is the change in DC output for an eight hour period after a half-hour warm-up at 25C, with the input voltage held constant at the rated input/output.
Avoid prolonged use under over-load.
Series/Parallel operation with other model is not possible.
Derating is required when operated with chassis and cover.
E-38
