This document was generated on 04/16/2010
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Description:
0538660870
Active
1.60mm (.063") Pitch Board-to-Board Panel Detachable PCB Header, Surface Mount, 8
Circuits, Gold (Au) Selective Plating, Tape-and-Reel Packaging, Lead-free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-54092-002 (PDF)
RoHS Certificate of Compliance (PDF)
Series
PCB Headers
53866
Board-to-Board
Panel Detachable
N/A
image - Reference only
EU RoHS
China RoHS
ELV and RoHS
Compliant
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
General
Product Family
Series
Application
Comments
Product Name
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Mated Height (in)
Mated Height (mm)
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PCB Locator
PCB Retention
PCB Thickness Recommended (in)
PCB Thickness Recommended (mm)
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Plating min: Mating (µin)
Plating min: Mating (µm)
Plating min: Termination (µin)
Plating min: Termination (µm)
Polarized to Mating Part
Polarized to PCB
Shrouded
Stackable
Temperature Range - Operating
Termination Interface: Style
No
8
8
Black
20,000
No
No
No
None
None
0.720 In
18.30 mm
Phosphor Bronze
Gold
Tin
High Temperature Thermoplastic
2
Vertical
Yes
None
0.062 In
1.60 mm
Embossed Tape on Reel
0.063 In
1.60 mm
20
0.5
40
1
No
No
Fully
No
-40°C to +105°C
Through Hole and Surface Mount
Search Parts in this Series
53866Series
Mates With
54092-0819 Board-to-Board Panel
Detachable PCB Receptacles
Electrical
Current - Maximum per Contact
Voltage - Maximum
1A
125V
