SPECIFICATIONS
Current rating:
Operating voltage:
Contact material:
Contact plating:
Contact resistance:
Insulator material:
Insulator resistance:
Withstanding:
Operating temperature:
5 amps
250VAC
Phosphor bronze
Tin, gold or duplex over nickel
10 milliohms max.
PBT, glass reinforced, UL94V-0
5,000 megohms min.
1,000 VAC for 1 min.
-55˚C to 125˚C
A
B
C
E
C
C
A
Straight
D
Reverse Right Angle
(RRA)
C
D
Right Angle
(RA)
E=Overall pin length
E
F
RoHS compliant
Rev.
A
B
C
D
1
Series
Insulator
Rows
Total Contacts
Type
APH
X
X
XX
XX
Pin header, Blank=.100” (2.54mm) 1=Single Single row 1-40 Blank=Straight
.100” pitch C=.059” (1.5mm)
2=Double Dual row 2-80
RAXX=Right angle
D=.067” (1.7mm)
3=Triple Triple row 3-120 RRAXX=Reverse right angle
XX=D1,U1, or custom if blank,
D2,D3,U2
SM=Surface mount
Date
03/01/05
01/04/06
05/14/08
8/13/08
2
Contact length
XXX
SDA=.240”mating
SDB=.318”mating
CSL=(A/E) [Straight]
CSL=(A/C/E) [RA]
Plating
XX
GDXX=Gold
SGXX=Duplex
TN=Tin
XX=Flash if blank;
15, 30, or 50µ”
E
F
G
Description
Add RoHS
Type
CSL
DWG
Approved
Tom
Tom
Greg
Greg
3
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
4
Date
08/10/99
08/10/99
08/10/99 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
APH-1-XX-XX-SDA-XX
7
8
9
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Pin header, single row, 0.100” pitch
G
