ALUMINUM ELECTROLYTIC CAPACITOR
GMX
7mm
高度 立式
105°C
小型超½阻抗品
7mm Height, Ultra Low Impedance Series
7mm
i
1,000
105
i
i
Ultra low impedance for high frequency circuit application
i
Life guaranteed 1,000 hours/105°C.
i
Specifications
Item
Operating Temperature
range
Rated Voltage
Capacitance Range
容量範圍
Capacitance Tolerance
Leakage Current
Dissipation Factor
(120Hz, 20°C)
Temperature
Characteristics
(120Hz)
Performance Characteristics
-40 + 105°C
6.3V
∼
50V
4.7
∼
330
µF
±20%
(120Hz, 20°C)
I
≤
0.01CV or 3
µA,
whichever is greater after 2 minutes application of rated voltage.
Rated voltage (V)
Tan
δ
(max.)
Rated voltage (V)
Z (-40°C) / Z (20°C)
Z (-55°C) / Z (20°C)
Capacitance change
Tan
δ
Leakage current
6.3
0.24
6.3
3
5
10
0.20
10
2
4
Within
±25%
of initial value
200% or less of initial specified value
Initial specified value or less
16
0.16
16
2
4
25
0.14
25
2
3
35
0.12
35
2
3
Impedance Ratio / Stability at Low Temperature
After 1,000 hours application of WV at 105°C, capacitor shall meet the characteristics requirements mentioned below.
Load Life
Shelf Life
After leaving capacitors under no load at 105°C for 1,000 hours and applying voltage according to JIS C5102 and C5141, they
shall meet the specified value as load life characteristics listed above.
i
Dimension
D
φ
P
4
1.5
0.45
5
2.0
0.45
6
2.5
0.45
φ
d
i
Standard Products Table
WV(SV)
Cap(µF)
4.7
10
15
22
33
47
68
100
150
220
330
6.3 x 7
6.3 x 7
0.24
0.29
280
280
6.3 x 7
6.3 x 7
6.3 x 7
5x7
0.49
160
4x7
5x7
6.3
(10)
10
(13)
16
(20)
4x7
4x7
1.15
0.49
0.24
0.24
0.29
0.29
90
160
280
280
280
280
5x7
5x7
6.3 x 7
6.3 x 7
6.3 x 7
6.3 x 7
6.3 x 7
25
(32)
4x7
1.15
0.49
0.49
0.24
0.24
0.24
0.29
90
160
160
280
280
280
280
5x7
6.3 x 7
6.3 x 7
6.3 x 7
6.3 x 7
D
φ
x L (mm)
35
(44)
1.15
0.49
0.29
0.29
0.29
0.29
90
160
280
280
280
280
1.15
0.49
90
160
5x7
0.24
0.24
0.29
280
280
280
6.3 x 7
6.3 x 7
6.3 x 7
Case Size
Imp. ripple
Impedance: (Ω) max. at 20°C 100KHz
Rated Ripple (mA rms) at 105°C 100KHz
Embedded System
