DATA SHEET
Formerly
HF/BS9151 F0007
2PDT HALF CRYSTAL CAN RELAY
DEUTSCH LTD
RELAY
Key Features
•
•
•
•
Hermetically Sealed
BS9000 Approval
Low Level capability
Small size for high density packaging
TYPE HF
Wiring Schematic
23
2
a
1
21
b
22
3
Specification
General
Contact Arrangement
Weight
Mating Bases
2 Pole changeover (2PDT) break before make.
8.7 g (mounting style 01)
Solder Contacts – Order Part No. 4223-1
Crimp Contacts – Order Part No. 420204
2A resistive, 10
5
operations at 28 VDC
1A resistive, 10
5
operations at 115 VRMS 400 Hz
6
Low level,10 operations (Typical 5 VDC, 10mA)
7
5 x 10 Operations (If applicable)
3.5 ms nominal
5 ms max (excluding bounce)
1 ms nominal
5 ms max. (excluding bounce)
3 ms max.
o
All measurements at 25 C and nominal voltage
Performance
Contact Rating/Life
Mean Mechanical Life
Operate Time
Release Time
Bounce Time
Environmental
Temperature Range
Shock
Vibration
Linear Acceleration
Bump
Climatic
Salt Mist
-65
o
C to +125
o
C
490 m/s
2
(50g) for 11 ms
60 to 2000 Hz at 196 m/s
2
(20g) acceleration
10 to 60 Hz at 1.5mm amplitude
(Applies to mounting variant 01)
980 m/s
2
(100g)
2
4000 bumps at 390 m/s (40g), 6ms duration. (If
applicable)
BS 2011 Test Z/ABDM procedure 1
BS 2011 Part 2.1 Kb severity 2
Data Sheet No
DSHF-0305
SHEET 1 OF 4
Ordering Information
See sheet 4
Design authority and manufacture by Barnbrook Systems Limited
Barnbrook Systems reserves the right to alter specifications and design without notice
BARNBROOK SYSTEMS LIMITED, 25 FAREHAM PARK ROAD, HAMPSHIRE, PO15 6LD
TEL NO: +44(0)1329 847722 FAX: +44(0)1329 844232 E-mail:
sales@barnbrook.co.uk
www.barnbrook.com
Quality Approvals
BS EN ISO 9001:2000
EASA Part 21 Subpart G
UK.21G.2069
EASA Part 145
UK.145.01008
BCAR A8-8
CAA DA1/9289/90
Q 11271
DATA SHEET
RELAY
TYPE HF
Electrical
Contact Resistance
Code 01 contacts 50 mΩ max measured at open circuit
voltage of 5 V and current of 10 mA
Code 02 contacts 50 mΩ max measured at open circuit
voltage of 10 mV and current of 10 mA
500 Megohms min – between any two isolated terminals
500 Megohms min – between terminals and case
Measured at 500 VDC and +25
o
C
500 VRMS, 50 Hz, at sea level, between terminals and
case, between two sets of contacts and between open
contacts of a set
350 VRMS, 50 Hz, at 20 mbar air pressure (87,000ft)
between all terminals and case
Closed contacts to case
4 pF
Open contacts to case
2 pF
Between contacts of a set
2 pF
Between the two contact sets
4 pF
The maximum operate power that can be applied to the
coil is 1.0 W at +25
o
C de-rated linearly to 0.8 W at +125
o
C
Insulation Resistance
Dielectric Strength
Capacitance
Coil Dissipation
TERMINATION VARIANTS
BS Ref 11
BS Ref 12
BS Ref 13
3.30
2.50
0.81
0.71 Dia
5.31
3.60
0.81
0.71 Dia
Contrast bead
5.31
4.55
3.40
2.90
0.81
0.71 Dia
Contrast bead
Contrast bead
5.08
5.08
5.08
5.08
5.08
5.08
10.16
15.24
10.16
15.24
10.16
15.24
Data Sheet No
DSHF-0305
SHEET 2 OF 4
All dimensions are in millimetres. Tolerances
±
0.25 unless otherwise stated
BARNBROOK SYSTEMS LIMITED, 25 FAREHAM PARK ROAD, HAMPSHIRE, PO15 6LD
TEL NO: +44(0)1329 847722 FAX: +44(0)1329 844232 E-mail:
sales@barnbrook.co.uk
www.barnbrook.com
Quality Approvals
BS EN ISO 9001:2000
EASA Part 21 Subpart G
UK.21G.2069
EASA Part 145
UK.145.01008
BCAR A8-8
CAA DA1/9289/90
Q 11271
DATA SHEET
MOUNTING VARIANTS
BS Ref 01/11*
HF Ref 01
BS Ref 02
10.46
34.00 max
20.60 max
9.50
0.80
10.5
max
4.40 U.N.C.
Contrast Bead
Termination
Variant
10.40
max
0.80
2 holes
3.00 Dia
6.35
6.35
27.40
27.00
RELAY
TYPE HF
BS Ref 03
HF Ref 03
HF Ref 02
5.08
Contrast Bead
Contrast Bead
BS Ref 04
HF Ref 25
BS Ref 05/09*/10
HF Ref 05
BS Ref 06
HF Ref 95
10
0
2.50
0.50
min
0.50
min
3.17
1.30
4.80
2.20
1.30
Contrast Bead
Contrast Bead
3.10
3.10
Contrast Bead t Bead
Contras
Contrast Bead
27.00
27.40
34.00 max
27.00
27.40
34.00 max
BS Ref 07
BS Ref 08
BS
Mounting
Variant
2 holes
3.10 Dia
27.40
27.00
0.70
4.80
5.08
Contrast Bead
2 holes
3.10 Dia
34.00 max
0.70
27.00
27.40
34.00 max
Contrast Bead
Equivalent
Vibration
HF
Level
Mounting
2
M/s
Variant
01
01
196*
02
02
98
03
03
196
04
25
196
05
05
196
06
95
196
07
-
196
08
-
196
09
-
196
10
-
196
11
-
196*
* Body of relay must be rigidly
mounted by epoxy cement.
Data Sheet No
DSHF-0305
SHEET 3 OF 4
* BS Ref 09 – Underside of bracket to be free of paint
* BS Ref 10 – Both sides of bracket to be free of paint
* BS Ref 11 – Free of paint
All dimensions are in millimetres. Tolerances
±
0.25 unless otherwise stated.
Can dimensions shown in Ref 01 apply to all variations. All termination variants allowable.
BARNBROOK SYSTEMS LIMITED, 25 FAREHAM PARK ROAD, HAMPSHIRE, PO15 6LD
TEL NO: +44(0)1329 847722 FAX: +44(0)1329 844232 E-mail:
sales@barnbrook.co.uk
www.barnbrook.com
Quality Approvals
BS EN ISO 9001:2000
EASA Part 21 Subpart G
UK.21G.2069
EASA Part 145
UK.145.01008
BCAR A8-8
CAA DA1/9289/90
Q 11271
DATA SHEET
RELAY
TYPE HF
ORDERING INFORMATION
BS9151F0007- 01- 03- 05- 12
HF 12 05 A OO
Termination
Mounting Style
Coil Variant
Contact Rating
BS Only
(refer to Page 2)
(refer to Page 3)
(see table below)
(refer to Page 2)
Modification Letter
(HF Only – OO for standard relay)
COIL VARIANTS AND OPERATING CHARACTERISTICS
BS
Reference
BS
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
HF
-
S6
A
-
S7
B
-
S2
D
-
S4
E
F
K
C
o
Resistance
ohms +/-
10%
40
42
60
150
210
320
675
830
1250
2500
2800
3500
40
700
700
Must
Operate
volts DC
3.6
3.6
3.6
7.2
7.2
7.2
14.4
14.4
14.4
28.8
28.8
28.8
3.0
14.4
10.6
Must
Release
volts DC
0.30
0.30
0.30
0.60
0.60
0.60
1.20
1.20
1.20
2.40
2.40
2.40
0.25
1.20
0.88
Maximum
volts DC
7.2
7.2
7.2
14.4
14.4
14.4
32.0
32.0
32.0
57.6
57.6
57.6
6.0
32.0
24.0
Nominal Volts
DC
6
6
6
12
12
12
24 – 26.5
24 – 26.5
24 – 26.5
48
48
48
5
24 – 26.5
20
Data Sheet No
DSHF-0305
SHEET 4 OF 4
All values measured at +25 C
