0805 CHIP INDUCTORS
Outgassing Compliant Chip Inductors
AE336RAA
The AE336RAA inductors provide exceptional Q values,
even at high frequencies. They have a ceramic body and
wire wound construction to provide the highest SRFs
available in 0805 size.
This robust version of Coilcraft’s standard 0805CS series
features high temperature materials that pass NASA low
outgassing specifications and allow operation in ambi-
ent temperatures up to 155°C. The leach-resistant base
metalization with tin-lead (Sn-Pb) terminations ensures
the best possible board adhesion.
Q
min
3
SRF min
4
(MHz)
5000
5000
5000
4760
4440
3840
3560
3460
3180
2560
2480
2080
1920
2060
1720
1520
1600
1440
1360
1280
1200
1060
1060
1000
880
880
730
730
650
610
580
520
480
300
260
220
240
Part
number
1
Inductance
2
(nH)
2.8 @ 250 MHz
3.0 @ 250 MHz
3.3 @ 250 MHz
5.6 @ 250 MHz
6.8 @ 250 MHz
7.5 @ 250 MHz
8.2 @ 250 MHz
10 @ 250 MHz
12 @ 250 MHz
15 @ 250 MHz
18 @ 250 MHz
22 @ 250 MHz
24 @ 250 MHz
27 @ 250 MHz
33 @ 250 MHz
36 @ 250 MHz
39 @ 250 MHz
43 @ 200 MHz
47 @ 200 MHz
56 @ 200 MHz
68 @ 200 MHz
82 @ 150 MHz
91 @ 150 MHz
100 @ 150 MHz
110 @ 150 MHz
120 @ 150 MHz
150 @ 100 MHz
180 @ 100 MHz
220 @ 100 MHz
240 @ 100 MHz
270 @ 100 MHz
330 @ 100 MHz
390 @ 100 MHz
470 @ 50 MHz
560 @ 25 MHz
680 @ 25 MHz
820 @ 25 MHz
Percent
tolerance
5
5
5
5
5
5
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2
5,2,1
5,2,1
5,2,1
5,2
5,2
5,2
5,2
5,2
5,2,1
5,2
5,2
5,2
DCR max
5
(Ohms)
0.06
0.06
0.08
0.08
0.11
0.14
0.12
0.10
0.15
0.17
0.20
0.22
0.22
0.25
0.27
0.27
0.29
0.34
0.31
0.34
0.38
0.42
0.48
0.46
0.48
0.51
0.56
0.64
0.70
1.00
1.00
1.40
1.50
1.76
1.90
2.20
2.35
Imax
(mA)
800
800
600
600
600
600
600
600
600
600
600
500
500
500
500
500
500
500
470
460
440
400
390
390
390
380
340
340
330
270
260
230
210
230
210
190
170
AE336RAA020JSZ
AE336RAA3N0JSZ
AE336RAA030JSZ
AE336RAA050JSZ
AE336RAA060JSZ
AE336RAA070JSZ
AE336RAA080_SZ
AE336RAA100_SZ
AE336RAA120_SZ
AE336RAA150_SZ
AE336RAA180_SZ
AE336RAA220_SZ
AE336RAA240_SZ
AE336RAA270_SZ
AE336RAA330_SZ
AE336RAA360_SZ
AE336RAA390_SZ
AE336RAA430_SZ
AE336RAA470_SZ
AE336RAA560_SZ
AE336RAA680_SZ
AE336RAA820_SZ
AE336RAA910_SZ
AE336RAA101_SZ
AE336RAA111_SZ
AE336RAA121_SZ
AE336RAA151_SZ
AE336RAA181_SZ
AE336RAA221_SZ
AE336RAA241_SZ
AE336RAA271_SZ
AE336RAA331_SZ
AE336RAA391_SZ
AE336RAA471_SZ
AE336RAA561_SZ
AE336RAA681_SZ
AE336RAA821_SZ
57 @ 1000 MHz
61 @ 1000 MHz
48 @ 1000 MHz
75 @ 1000 MHz
54 @ 1000 MHz
56 @ 1000 MHz
63 @ 1000 MHz
57 @ 500 MHz
46 @ 500 MHz
41 @ 500 MHz
48 @ 500 MHz
59 @ 500 MHz
59 @ 500 MHz
56 @ 500 MHz
64 @ 500 MHz
57 @ 500 MHz
44 @ 250 MHz
45 @ 250 MHz
44 @ 250 MHz
49 @ 250 MHz
52 @ 250 MHz
51 @ 250 MHz
49 @ 250 MHz
54 @ 250 MHz
38 @ 250 MHz
52 @ 250 MHz
33 @ 100 MHz
37 @ 100 MHz
36 @ 100 MHz
36 @ 100 MHz
36 @ 100 MHz
36 @ 100 MHz
34 @ 100 MHz
24 @ 50 MHz
21 @ 50 MHz
21 @ 50 MHz
23 @ 50 MHz
1. When ordering, please specify
tolerance
and
testing
codes:
AE336RAA821GSZ
Tolerance: F
= 1%
G
= 2%
J
= 5%
Testing:
Z
= COTS
H
= Screening per Coilcraft CP-SA-10001
N
= Screening per Coilcraft CP-SA-10003
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/HP 4286A impedance analyzer or equivalent with Coilcraft-provided correlation pieces.
3. Q measured using an Agilent/HP 4291A with an Agilent/HP 16197A test fixture or equivalents.
4. SRF measured on an Agilent 8753ES or equivalent with a Coilcraft CCF1297 test fixture.
5. DCR measured on a Keithley micro-ohmmeter or equivalent and a Coilcraft CCF858 test fixture.
6. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
®
Specifications subject to change without notice.
Please check our website for latest information.
Document AE100-1
Revised 12/05/11
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2011
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
0805 CHIP INDUCTORS
AE336RAA Series (0805)
Typical Q vs Frequency
100
90
80
68 nH
39 nH
Typical L vs Frequency
12 nH
22 nH
1000
3.3 nH
220 nH
6.8 nH
Inductance (nH)
70
120 nH
100
100 nH
39 nH
15 nH
Q Factor
60
50
40
30
20
10
0
270 nH
10
3.3 nH
1
10
100
1000
10,000
10
100
1000
Frequency (MHz)
Core material
Ceramic
Terminations
Tin-lead (63/37) over silver-platinum-glass frit
Ambient temperature
–55°C to +125°C with
Imax
current, +125°C
to +155°C with derated current
Storage temperature
Component: –55°C to +155°C.
Packaging: –55°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +155 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Enhanced crush-resistant packaging
2000 per 7″ reel
Plastic tape: 8 mm wide, 0.23 mm thick, 4 mm pocket spacing,
1.65 mm pocket depth
Frequency (MHz)
Current Derating
120
110
100
90
80
70
60
50
30
20
10
0
-40
-20
0
20
40
60
80
100
120
140 160
40
Percent of rated
I
rms
B
overall
F
A
G
F
E
terminal
C
I
J
I
H
Ambient temperature (°C)
D
Terminal wraparound:
approx 0.015/0,38 both ends
Suggested
Land Pattern
H
1,78
I
1,02
J
0,76 mm
A max B max C max D ref
2,29
1,73
1,52
E
F
0,51
G
1,02
0.090 0.068 0.060 0.020 0.050 0.020 0.040 0.070 0.040 0.030 inches
0,51 1,27
All dimensions are without solder applied to the terminations. For
maximum dimensions with solder, add 0.006 inches / 0,152 mm.
®
Specifications subject to change without notice.
Please check our website for latest information.
25°C
Document AE100-2
Revised 12/05/11
1102 Silver Lake Road
Cary IL 60013
© Coilcraft, Inc. 2011
Phone 800-981-0363
Fax 847-639-1508
E-mail cps@coilcraft.com
Web www.coilcraft-cps.com
