Part Number:
Status:
Overview:
Description:
0877591675
Active
milligrid
2.00mm (.079") Pitch Milli-Grid™ Header, Surface Mount, Vertical, 16 Circuits, 0.76µm
(30µ") Gold (Au) Selective Plating, with Pick-and-Place Cap, Tape and Reel Packaging,
without Press-fit Plastic Pegs, Lead-free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-87761-100 (PDF)
RoHS Certificate of Compliance (PDF)
image - Reference only
Series
Agency Certification
UL
E29179
General
Product Family
Series
Application
Overview
Product Name
PCB Headers
87759
Board-to-Board
milligrid
Milli-Grid™
Physical
Breakaway
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Glow-Wire Compliant
Guide to Mating Part
Keying to Mating Part
Lock to Mating Part
Mated Height (in)
Mated Height (mm)
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Number of Rows
Orientation
PCB Locator
PCB Retention
Packaging Type
Pitch - Mating Interface (in)
Pitch - Mating Interface (mm)
Pitch - Term. Interface (in)
Pitch - Term. Interface (mm)
Plating min: Mating (µin)
Plating min: Mating (µm)
Polarized to Mating Part
Polarized to PCB
Robotic Placement
Shrouded
Stackable
Temperature Range - Operating
Yes
16
16
Black
100
No
94V-0
No
No
None
None
0.150 In
3.80 mm
Phosphor Bronze
Gold
Tin
High Temperature Thermoplastic
2
Vertical
No
None
Embossed Tape on Reel
0.079 In
2.00 mm
0.079 In
2.00 mm
30
0.76
No
No
Pick and Place Cap
No
Yes
-55°C to +105°C
EU RoHS
China RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
87759Series
Mates With
79107 Milli-Grid™ Receptacle, Vertical,
Through Hole. 79108 Milli-Grid™ Flex-to-
Board, Vertical Receptacle. Milli-Grid™
Receptacle, Surface Mount. 79109. 87381
Termination Interface: Style
Surface Mount
Electrical
Current - Maximum per Contact
Voltage - Maximum
2A
125V
Solder Process Data
Duration at Max. Process Temperature (seconds)
Lead-free Process Capability
Max. Cycles at Max. Process Temperature
Process Temperature max. C
10
Reflow Capable (SMT only)
3
260
Material Info
Reference - Drawing Numbers
Packaging Specification
Product Specification
Sales Drawing
PK-89990-485
PS-87761-100
SD-87759-118
