PT50SN16_15

Description
DIODE
File Size458KB,2 Pages
ManufacturerNI
Websitehttps://www.ni.com
Download Datasheet Compare View All

PT50SN16_15 Overview

DIODE

DIODE
■回路図
CIRCUIT
50A Avg 1600 Volts
■外½寸法図
OUTLINE DRAWING
PT50SN16
Dimension:[mm½
■最大定格
Maximum Ratings
項 目
Parameter
くり返しピーク逆電圧
Repetitive Peak Reverse Voltage
非くり返しピーク逆電圧
Non Repetitive Peak Reverse Voltage
項 目
Parameter
平均出力電流
Average Rectified Output Current
サージ順電流
*1
Surge Forward Current
電流二乗時間積
*1
I Squared t
動½接合温度範囲
Operating Junction Temperature Range
保存温度範囲
Storage Temperature Range
絶縁耐圧
Isolation Voltage
ベース部
Mounting
締付トルク
Mounting Torque
主端子部
Terminal
*1
*1
記号
Symbol
V
RRM
V
RSM
記号
Symbol
Io
(AV)
I
FSM
I
2
t
Tjw
Tstg
Viso
端子-ベース間,AC
1
分間
Terminal to Base, AC 1min.
½½マル½ンパ½ンド塗布
Greased
耐圧クラス
Grade
PT50SN16
1600
1700
条 件
Conditions
三相全波整流
Tc=Tt=125℃
3-Phase Full Wave, Rectified
(Terminal)
50Hz
正弦半波,1 ½½½ル,非くり返し
Half Sine Wave, 1Pulse, Non-Repetitive
2½10ms
定格値
Max.Rated Value
50
450
1000
-40
½
+150
-40
½
+125
2500
M5
M5
2.4
½
2.8
2.4
½
2.8
½
Unit
V
V
½
Unit
A
A
A
2
½
V
N・m
N・m
■電気的特性
Electrical Characteristics
項 目
Parameter
ピーク逆電流
Peak Reverse Current
ピーク順電圧
Peak Forward Voltage
*1
*1
記号
Symbol
I
RM
V
FM
(chip)
V
FM
(terminal)
Rth(j-c)
Rth(c-f)
条 件
Conditions
Tj=150℃,V
RM
=V
RRM
特性値(最大)
Maximum Value
10
1. 2
1.25
接合部-ケース間(トータル)
Junction to Case, (Total)
½½½½-フ½ン間(ト½タル),½½マル½ンパ½ンド塗布
Case to Fin (Total), Greased
0. 10
0. 06
℃/W
℃/W
½
Unit
mA
Tj= 25℃,I
FM
=50A
V
熱抵抗
Thermal Resistance
接触熱抵抗
Thermal Resistance
質 量 --- 約
180g
Approximate Weight
*1:1アーム½りの値 Value Per 1 Arm
