2.5SB
HEADER
2.5mm
(.098") pitch
Headers
The SB headers can be used to connect
any 2.5mm (.098") receptacles to printed
circuit boards. They can also be used to
directly connect PC boards. They come in
pitches of 2.5mm (.098") and in both top
entry and side entry type models.
2.54mm (.100") pitch SB headers are also
available. In addition, 2.0mm (.079") pitch
BC headers are available.
Specifications –––––––––––––––––––
• Current rating: 3A AC, DC
• Voltage rating: 250V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Post: Brass, copper-undercoated
tin/lead-plated
• Wafer: Nylon 66, UL94V-0, natural (white)
• Pitch: 2.5mm(.098")
• Number of circutis: 2 to 20
Standards ––––––––––––––––––––––
0
1
Recognized E60389
Certified LR20812
447
2.5SB
HEADER
Header ––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
Top entry type
Model No.
SB( )P-HVQ-A
SB( )P-HVQ-B
SB( )P-HVQ-C
SB( )P-HVQ-CA
SB( )P-HVQ-S
SB( )P-HVQ-N
SB( )P-HVQ-15
SB( )P-HVQ-16
SB( )P-HVQ-22
SB( )P-HVQ-23
SB( )P-HVQ-24
SB( )P-HVQ-27
SB( )P-HVQ-28
SB( )P-HVQ-29
SB( )P-HVQ-30
SB( )P-HVQ-34
Dimensions mm(in.)
A
5.0 (.197)
4.0 (.157)
0.4 (.016)
3.4 (.134)
3.4 (.134)
6.35(.250)
6.3 (.248)
3.3 (.130)
3.4 (.134)
3.5 (.138)
3.4 (.134)
4.0 (.157)
1.5 (.059)
2.5 (.098)
3.4 (.134)
3.3 (.130)
B
16.5 (.650)
8.7 (.343)
10.5 (.413)
7.5 (.295)
6.0 (.236)
6.35(.250)
13.7 (.539)
7.5 (.295)
11.1 (.437)
5.7 (.224)
13.7 (.539)
3.5 (.138)
5.1 (.201)
14.0 (.551)
14.8 (.583)
3.3 (.130)
C
24.8(.976)
16.0(.630)
14.2(.559)
14.2(.559)
12.7(.500)
16.0(.630)
23.3(.917)
14.1(.555)
17.8(.701)
12.5(.492)
20.4(.803)
10.8(.425)
9.9(.390)
19.8(.780)
21.5(.846)
9.9(.390)
2.5(.098)
2.5(.098) X
(number of circuits -1)
2.5(.098) X
(number of circuits)
0.64(.025)
2.4(.094)
[1.25(.049)]
A
3.3
(.130)
C
B
*The number of circuits (2 to 20) will be filled in the parentheses above.
Side entry type
B
Model No.
MB( )P-90
MB( )P-90H
MB( )P-90S
MB( )P-90-2
Dimensions mm(in.)
A
3.5(.138)
3.4(.134)
4.3(.169)
2.3(.091)
B
3.5(.138)
7.6(.299)
7.9(.311)
2.5(.980)
C
8.8(.346)
9.7(.382)
8.3(.327)
7.6(.299)
*The number of circuits (2 to 20) will be filled in the parentheses above.
2.5(.098)
2.5(.098) X
(number of circuits -1)
2.5(.098) X
(number of circuits)
0.64(.025)
2.4(.094)
1.25(.049)
PC board layout
(viewed from soldering side)
––––––––––––––––––––––––––––––––––––––
2.5
±
0.05
(.098
±
.002)
Note:
1. Tolerances are non-cumulative: ±0.05mm(±.002" ) for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing
method. The dimensions above should serve as a guideline.
Contact JST for details.
1.25(.049)
min.
0.9
+0.1
0
(.035
+.004
)dia.
0
448
A
3.3
(.130)
C
