SINGLE-IN-LINE SOCKETS
Solder Tail
Double Row
2,54
●
2,54
2,54
0,38
0,25
0,64
0,46
5,08
●
Series 410, 411, 415
Series 41X double row strip
sockets are on 2,54 grid.
Various solder pins available
(standard, long for multi-layer
boards, very low and ultra low).
Using Mill-Max pin #’s 1001, 0134,
0501 & 1534.
Hi-Rel, 4-finger BeCu #30 & #12
clips are rated at 3 amps.
See pages 207 & 208 for details.
3,71
2,41
2,79
4,19
●
0,51
3,18
Fig. 1
0,38 0,64
0,25 0,46
2,54
Ordering Information
Series 410...001
Standard Solder Tail
Fig. 1
4,19
410-XX-2_ _-41-001000
Specify # of pins
Series 411...001
02-64
Long Solder Tail
3,81
2,62
2,79
0,51
4,32
Fig. 2
411-XX-2_ _-41-001000
Specify # of pins
02-64
Very Low Profile
2,54
Fig. 2
0,38 0,64
0,25 0,46
Series 415...001
Fig. 3
2,79
3,1
415-XX-2_ _-41-001000
Specify # of pins
02-64
Ultra Low Profile
3,84
2,44
Series 415...003
0,76
2,74
Fig. 4
415-XX-2_ _-41-003000000
Specify # of pins
02-72
(Standard Insulator is High Temperature)
For RoHS compliance,
select
plating code.
For the all gold option
(XX=13) also change
part number from
41X-XX-2XX-41-00X000
to
41X-13-2XX-41-00X100
2,54
Fig. 3
0,38
0,25
0,56
0,46
1,8
3,94
1,8
2,41
2,41
XX=Plating Code
See Below
2,54
SPECIFY PLATING CODE XX=
13
0,76µm Au
91
10µ” Au
93
99
41
43
44
Sleeve (Pin)
0,25µm Au
200µ” Sn/Pb
5,08µm Sn/Pb
200µ” Sn/Pb
0,76µm Au
200µ” Sn/Pb
200µ” Sn
5,08µm Sn
200µ” Sn
10µ” Au
0,76µm Au
200µ” Sn
Fig. 4
Contact (Clip)
w w w. m i l l - m a x . c o m
51
516-922-6000
