Notes: (Ref) – Dimensions provided for reference only. No dimensions are provided for B, P or R because low profile cases do not have a bevel or a notch.
* MIL–C–55365/8 specified dimensions
Table 1 – Ratings & Part Number Reference
Rated
Voltage
VDC
4
4
4
6.3
6.3
6.3
10
16
16
20
25
25
VDC
Rated
Cap
µF
680
1000
1000
470
680
680
330
150
220
100
68
100
µF
Case Code/
Case Size
KEMET/EIA
X/7343-43
X/7343-43
E/7360-38
X/7343-43
X/7343-43
E/7360-38
X/7343-43
X/7343-43
X/7343-43
X/7343-43
X/7343-43
E/7360-38
KEMET/EIA
KEMET Part
Number
(See below for
part options)
T513X687(1)004(2)(3)(4)(5)
T513X108(1)004(2)(3)(4)(5)
T513E108(1)004(2)(3)(4)(5)
T513X477(1)006(2)(3)(4)(5)
T513X687(1)006(2)(3)(4)(5)
T513E687(1)006(2)(3)(4)(5)
T513X337(1)010(2)(3)(4)(5)
T513X157(1)016(2)(3)(4)(5)
T513X227(1)016(2)(3)(4)(5)
T513X107(1)020(2)(3)(4)(5)
T513X686(1)025(2)(3)(4)(5)
T513E107(1)025(2)(3)(4)(5)
(See below for
part options)
DC
Leakage
μA @ +20ºC
Max/5 Min
27.2
40.0
40.0
29.6
42.8
42.8
33.0
24.0
35.2
20.0
17.0
25.0
μA @ +20ºC
Max/5 Min
DF
% @ +20ºC
120 Hz Max
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
10.0
8.0
8.0
8.0
% @ +20ºC
120 Hz Max
Standard
ESR
mΩ @ +20ºC
100 kHz Max
30
23
18
30
45
23
35
40
40
45
45
50
mΩ @ +20ºC
100 kHz Max
Low ESR
mΩ @ +20ºC
100 kHz Max
N/A
18
10
N/A
23
12
N/A
30
25
40
N/A
N/A
mΩ @ +20ºC
100 kHz Max
Ultra-low
ESR
mΩ @ +20ºC
100 kHz Max
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
35
N/A
N/A
mΩ @ +20ºC
100 kHz Max
Rated Voltage
Rated
Cap
Case Code/
Case Size
KEMET Part Number
DC
Leakage
DF
Standard ESR
Low ESR
Ultra-low ESR
(1) To complete KEMET part number, insert M for ±20%, K for ±10%. Designates Capacitance tolerance.
(2) To complete KEMET part number, insert B (0.1%/1,000 hours), or A = N/A. Designates Reliability Level.
(3) To complete KEMET part number, insert B = Gold Plated, C = Hot solder dipped, H = Solder Plated, K = Solder Fused or T = 100% Tin (Sn). Designates
Termination Finish.
(4) To complete KEMET part number, insert 61 = None, 62 = 10 cycles +25°C, 63 = 10 cycles -55°C +85°C after Weibull or 64 = 10 cycles -55°C +85°C before
Weibull. Designates Surge current option.
(5) To complete KEMET part number, insert 10 = Standard ESR, 20 = Low ESR or 30 = Ultra Low ESR. Designates ESR option.
15
Refer to Ordering Information for additional detail.
