15ETX06FP

Description
15 A, 600 V, SILICON, RECTIFIER DIODE, TO-220AC
CategoryDiscrete semiconductor    diode
File Size103KB,7 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric Compare View All

15ETX06FP Online Shopping

Suppliers Part Number Price MOQ In stock
15ETX06FP - - View Buy Now

15ETX06FP Overview

15 A, 600 V, SILICON, RECTIFIER DIODE, TO-220AC

15ETX06FP Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerVishay
Parts packaging codeTO-220AC
package instructionTO-220, FULL PACK-2
Contacts2
Reach Compliance Codeunknown
Is SamacsysN
Other featuresFREE WHEELING DIODE, LOW LEAKAGE CURRENT
applicationHYPERFAST SOFT RECOVERY HIGH POWER
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)1.8 V
JEDEC-95 codeTO-220AC
JESD-30 codeR-PSFM-T2
Maximum non-repetitive peak forward current170 A
Number of components1
Phase1
Number of terminals2
Maximum operating temperature175 °C
Maximum output current15 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum repetitive peak reverse voltage600 V
Maximum reverse recovery time0.032 µs
surface mountNO
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
Base Number Matches1
15ETX06PbF, 15ETX06FPPbF
Vishay High Power Products
Hyperfast Rectifier,
15 A FRED Pt
TM
FEATURES
15ETX06PbF
15ETX06FPPbF
• Benchmark ultralow forward voltage drop
• Hyperfast recovery time
• Low leakage current
• 175 °C operating junction temperature
Base
cathode
2
• Fully isolated package (V
INS
= 2500 V
RMS
)
• Lead (Pb)-free (“PbF” suffix)
• Designed and qualified for industrial level
1
Cathode
3
Anode
1
Cathode
3
Anode
DESCRIPTION/APPLICATIONS
State of the art hyperfast recovery rectifiers designed with
optimized performance of forward voltage drop, hyperfast
recovery time, and soft recovery.
The planar structure and the platinum doped life time control
guarantee the best overall performance, ruggedness and
reliability characteristics.
These devices are intended for use in PFC boost stage in
the AC-DC section of SMPS, inverters or as freewheeling
diodes.
Their extremely optimized stored charge and low recovery
current minimize the switching losses and reduce over
dissipation in the switching element and snubbers.
TO-220AC
TO-220 FULL-PAK
PRODUCT SUMMARY
t
rr
I
F(AV)
V
R
18 ns
15 A
600 V
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Peak repetitive reverse voltage
Average rectified forward current
Non-repetitive peak surge current
Peak repetitive forward current
Operating junction and storage temperatures
SYMBOL
V
RRM
I
F(AV)
I
FSM
I
FM
T
J
, T
Stg
T
C
= 133 °C
T
C
= 62 °C (FULL-PAK)
T
J
= 25 °C
TEST CONDITIONS
VALUES
600
15
170
30
- 65 to 175
°C
A
UNITS
V
ELECTRICAL SPECIFICATIONS
(T
J
= 25 °C unless otherwise specified)
PARAMETER
Breakdown voltage,
blocking voltage
Forward voltage
SYMBOL
V
BR
,
V
R
V
F
I
R
= 100 µA
I
F
= 15 A
I
F
= 15 A, T
J
= 150 °C
V
R
= V
R
rated
T
J
= 150 °C, V
R
= V
R
rated
V
R
= 600 V
Measured lead to lead 5 mm from package body
TEST CONDITIONS
MIN.
600
-
-
-
-
-
-
TYP.
-
2.3
1.5
0.1
40
20
8.0
MAX.
-
3.2
1.8
50
300
-
-
µA
pF
nH
V
UNITS
Reverse leakage current
Junction capacitance
Series inductance
I
R
C
T
L
S
* Pb containing terminations are not RoHS compliant, exemptions may apply
Document Number: 94006
Revision: 24-Nov-08
For technical questions, contact: diodes-tech@vishay.com
www.vishay.com
1
