Marker for terminal blocks - UC-TMF 6 BU CUS - 0824647
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Marker for terminal blocks, can be ordered: by sheet, blue, labeled according to customer specifications,
mounting type: snap into flat marker groove, for terminal block width: 6.2 mm, lettering field size: 5.6 x 5.1 mm
Your advantages
Labeling service: Phoenix Contact can custom-label all UniCard markers according to your requirements
The UC-TMF ... UniCard labeling range includes markers for products with tall and flat marker grooves
Key Commercial Data
Packing unit
GTIN
GTIN
Weight per Piece (excluding packing)
Custom tariff number
Country of origin
4046356359825
8.700 g
49119900
Germany
1 pc
Technical data
Dimensions
Width (a)
6 mm
Ambient conditions
Ambient temperature (operation)
Recommended storage conditions
-40 °C ... 120 °C
23 °C/50 % relative humidity. Storage in a dry and dark place in the
original packaging is recommended.
General
Color
Type
Components
Flammability rating according to UL 94
Material
blue
flat
free from silicone and halogen
V2
PA
01/01/2019 Page 1 / 3
https://www.phoenixcontact.com/in/products/0824647
Marker for terminal blocks - UC-TMF 6 BU CUS - 0824647
Technical data
General
RoHS compliant
Wipe resistance
Number of individual labels
Number of individual labels per row
Printability
Device
Test for substances that would hinder coating with paint or varnish
Result
Test specification weathering-resistance
Test duration
Wipe resistance test result
Salt spray test specification
Test duration
Salt spray testing result
Wipe resistance of test specification inscriptions
Result
Marking mounting type
Result
Oxygen index (DIN EN ISO 4589-2)
Class I
Class F
R22
R23
R24
Yes
DIN EN 61010-1 (VDE 0411-1)
80
10
UV LED technology
5147999 BLUEMARK CLED
VW PV 3.10.7:2005-02
Test passed
Following ISO 4892-2:2013-03
96 h
Test passed
DIN EN 60068-2-11:2000-02
96 h
Test passed
DIN EN 61010-1 (VDE 0411-1):2011-07
Test passed
snap into flat marker groove
Test passed
28,2%
3
2
HL 1 - HL 2
HL 1 - HL 2
HL 1 - HL 2
Standards and Regulations
Wipe resistance
Flammability rating according to UL 94
Fire protection for rail vehicles (DIN EN 45545-2) R22
Fire protection for rail vehicles (DIN EN 45545-2) R23
Fire protection for rail vehicles (DIN EN 45545-2) R24
DIN EN 61010-1 (VDE 0411-1)
V2
HL 1 - HL 2
HL 1 - HL 2
HL 1 - HL 2
Drawings
01/01/2019 Page 2 / 3
https://www.phoenixcontact.com/in/products/0824647
Marker for terminal blocks - UC-TMF 6 BU CUS - 0824647
Schematic diagram
1
1 2 3 4 5 6 7 8 9 10
2
① Horizontal
② Vertical
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
eCl@ss 9.0
24190208
24190208
27149103
27141100
27141100
27141137
27141137
27141137
ETIM
ETIM 2.0
ETIM 3.0
ETIM 4.0
ETIM 5.0
ETIM 6.0
EC000761
EC000761
EC000761
EC000761
EC000761
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
30211811
39121410
39121410
39121410
39131505
