ZFKDSA2,5-5,08-6: DescriptionBarrier Strip Terminal Block, 24A, 2.5mm2,; CategoryThe connector; File Size70KB，3 Pages; ManufacturerPHOENIX CONTACT; Websitehttps://www.phoenixcontact.com; Environmental Compliance

Download Datasheet Parametric Compare View All

ZFKDSA2,5-5,08-6 Overview

Barrier Strip Terminal Block, 24A, 2.5mm2,

ZFKDSA2,5-5,08-6 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	PHOENIX CONTACT
Reach Compliance Code	compli
Fastening method	SPRING LOADED
Installation type	BOARD
Number of channels	6
Rated current	24 A
Rated voltage	400 V
safety certificate	EAC
Terminal and terminal strip types	BARRIER STRIP TERMINAL BLOCK
Conductor cross section	2.5 mm2
Wire gauge	12 AWG

Preview

Download Datasheet

View All

https://www.phoenixcontact.com/us/products/1703651

PCB terminal block - ZFKDSA 2,5-5,08- 6 - 1703651

Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's

documentation. Our General Terms of Use for Downloads are valid

(http://phoenixcontact.com/download)

PCB terminal block, Nominal current: 24 A, Nom. voltage: 400 V, Pitch: 5.08 mm, Number of positions: 6,

Connection method: Spring-cage connection, Mounting: Wave soldering, Conductor/PCB connection direction: 45

°, Color: green

Key Commercial Data

Packing unit

Minimum order quantity

Weight per Piece (excluding packing)

Custom tariff number

Country of origin

1 pc

50 pc

7.6 g

85369010

Poland

Technical data

Dimensions

Length

Pitch

Dimension a

Constructional height

Length of the solder pin

Pin dimensions

Hole diameter

16.85 mm

5.08 mm

25.4 mm

15 mm

3.5 mm

0,8 x 0,8 mm

1.3 mm

General

Range of articles

Rated surge voltage (III/3)

Rated surge voltage (III/2)

Rated surge voltage (II/2)

Rated voltage (III/3)

Rated voltage (III/2)

Rated voltage (II/2)

Connection in acc. with standard

Nominal current I

N

ZFKDS(A) 2,5

4 kV

250 V

400 V

630 V

EN-VDE

24 A

05/19/2016 Page 1 / 3

ZFKDSA2,5-5,08-6 Related Products

	ZFKDSA2,5-5,08-6	1703651
Description	Barrier Strip Terminal Block, 24A, 2.5mm2,	Barrier Strip Terminal Block, 24A, 2.5mm2,
Is it Rohs certified?	conform to	conform to
Maker	PHOENIX CONTACT	PHOENIX CONTACT
Reach Compliance Code	compli	compliant
Fastening method	SPRING LOADED	SPRING LOADED
Installation type	BOARD	BOARD
Number of channels	6	6
Rated current	24 A	24 A
Rated voltage	400 V	400 V
safety certificate	EAC	EAC
Terminal and terminal strip types	BARRIER STRIP TERMINAL BLOCK	BARRIER STRIP TERMINAL BLOCK
Conductor cross section	2.5 mm2	2.5 mm2
Wire gauge	12 AWG	12 AWG
