S223-K1,6
General Information
Extended Product Type:
Product ID:
EAN:
Catalog Description:
Long Description:
S223-K1,6
GHS2230001R0257
4012233320400
Miniature Circuit Breaker - S220 - 3P - K
S223-K 1,6 Miniature Circuit Breaker K-Char.,10kA,1,6A,3P
Categories
Products
»
Low Voltage Products and Systems
»
Modular DIN Rail Products
»
Miniature Circuit Breakers MCBs
Ordering
Minimum Order Quantity:
Customs Tariff Number:
1 piece
85362010
Popular Downloads
Data Sheet, Technical Information:
2CDC414003D0201
Instructions and Manuals:
2CDC414003D0201
Dimensions
Product Net Width:
Product Net Depth:
Product Net Height:
Product Net Weight:
92 mm
183 mm
93 mm
0.54 kg
Technical
Standards:
Number of Poles:
Tripping Characteristic:
Rated Current (I
n
):
Rated Operational Voltage:
Power Loss:
Rated Insulation Voltage (U
i
):
Operational Voltage:
Rated Frequency (f):
Rated Ultimate Short-Circuit
Breaking Capacity (I
cu
):
Rated Service Short-Circuit
Breaking Capacity (I
cs
):
Overvoltage Category:
Pollution Degree:
Rated Impulse Withstand Voltage
(U
imp
):
Housing Material:
Actuator Type:
Contact Position Indication:
Degree of Protection:
Electrical Endurance:
Mechanical Endurance:
Terminal Type:
Screw Terminal Type:
Connecting Capacity:
IEC/EN 60947-2
UL 1077
3
K
1.6 A
acc. to IEC 60947-2 690 V AC
4,8 W
at Rated Operating Conditions per Pole 1,6 W
acc. to IEC/EN 60664-1 440 V
Maximum (Incl. Tolerance) 690 V AC
Maximum (Incl. Tolerance) 110 V DC
Minimum 12 V AC / 12 V DC
50 Hz
60 Hz
(690 V AC) 3 kA
(690 V AC) 3 kA
III
3
4 kV
Insulation Group I, RAL 7035
Insulation group II, black, sealable
Red ON / Green OFF
IP20
20000 AC cycle
20000 cycle
Screw Terminals
Cage Terminal
Flexible with Ferrule 0.75 ... 25 mm²
Flexible 0.75 ... 25 mm²
Rigid 0.75 ... 25 mm²
Stranded 0.75 ... 25 mm²
2 N·m
Pozidriv 2
TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715
TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
Tightening Torque:
Recommended Screw Driver:
Mounting on DIN Rail:
Mounting Position:
Any
Environmental
Ambient Air Temperature:
Ambient Air Temperature
Compensation:
Resistance to Shock acc. to IEC
10g / 20 shocks / 13 ms
60068-2-27:
Resistance to Vibrations acc. to IEC
5g, 20 cycles at 5 ... 150 ... 5 Hz with load 0.8 In
60068-2-6:
Environmental Conditions:
28 cycles
with 55 °C / 90-96 %
and 25 °C / 95-100 %
Operation -25 ... +45 °C
Storage -40 ... +70 °C
Yes
Technical UL/CSA
Maximum Operating Voltage
UL/CSA:
Connecting Capacity UL/CSA:
600 V AC
Busbar 6-36 AWG
Conductor 4 AWG
Interrupting Rating acc. to UL1077:
(690 V AC) 3 kA
Certificates and Declarations (Document Number)
Declaration of Conformity - CE:
RoHS Information:
2CDK403015D2704
2CDK400010K0201
Container Information
Package Level 1 Units:
Package Level 1 Width:
Package Level 1 Length:
Package Level 1 Height:
Package Level 1 Gross Weight:
3 piece
92 mm
183 mm
93 mm
1.67 kg
Classifications
Object Classification Code:
ETIM 4:
ETIM 5:
ETIM 6:
eClass:
UNSPSC:
F
EC000042 - Miniature circuit breaker (MCB)
EC000042 - Miniature circuit breaker (MCB)
EC000042 - Miniature circuit breaker (MCB)
7.0 27141901
39121614
Accessories
1 Products
Identifier
GHS2201904R0003
Description
S220-H11 - Auxiliary Contact
Type
S220-H11
Filter
Qty Unit Of Measure
1
piece
