ULTRA PRECISION THIN FILM
CHIP RESISTORS
RESISTORS
wCOILSwDELAY
LINES
Type BLU1206A
L
T
t
W
BLU SERIES
FEATURES
r
Industry’s widest range of precision chip resistors!
r
Tolerance to ±0.01%, TCR to 5 ppm/°C
r
Wattage rating up to 1/2W
r
Unlimited selection of resistance values
r
Low cost
“BLU-CHIP” Series offers unparalleled performance!
RCD’s expertise in the field of ultra-precision resistors since
1973, combined with the latest in automated chip resistor
production equipment, enables precision chip resistors at
prices comparable to lower grade devices. The BLU-chip
design features unsurpassed stability levels, extremely low
noise and voltage coefficient, as well as low inductance and
capacitance. Consult factory for availability of non-standard values.
EIA E-96 and E-24 values are standard in most sizes.
TCR
(P P M /°C )
25,50
100
25
50,100
25,50
100
5, 10
25,50,100
5, 10
25,50,100
10
25,50,100
10
25,50,100
S ta n da rd R e s ista nc e R a n ge
1
.0 1% -.05 %
N /A
N /A
N /A
N /A
100
Ω
-10K
100
Ω
-10K
100
Ω
-100K
100
Ω
-100K
100
Ω
-100K
100
Ω
-100K
100
Ω
-100K
100
Ω
-100K
100
Ω
-100K
100
Ω
-100K
.1 % -0 .25 %
N /A
100
Ω
- 10K
100
Ω
- 10K
10
Ω
- 100K
100
Ω
- 33K
10
Ω
- 33K
100
Ω
- 100K
100
Ω
-1M
100
Ω
-249K
49.9
Ω
- 1M
100
Ω
-130K
51
Ω
-240K
10
Ω
- 1M
10
Ω
- 1M
0 .5% -1%
33
Ω
- 22K
10
Ω
- 22K
100
Ω
- 10K
10
Ω
- 100K
L
.020±.004
[.5±.1]
D im e ns io ns
W
.01±.002
[.25±.05]
T
.014±.004
[.35±.1]
t
01±.005
[.25±.12]
.01±.005
[.25±.12]
CUSTOM OPTIONS
r
Option ‘P’: Pulse resistant design
r
Option ‘M’: Matched sets
r
Option ‘ER’: Burn-In for Hi-Rel applications
r
Option ‘B’: Increased power rating
r
Option ‘A’: Marking of resis. code (3 or 4 digits),
not available on BLU-0201 or BLU-0402
R C D Ty pe
W a tta ge
S td
B LU 0201
B LU 0402
B LU 0603
B LU 0805
B LU 1206
B LU 1210
B LU 1612
.025W .
.05W
.062W .
.10W .
.125W
.25W
.33W
O p t.B
.0375W
..075W
.093W
.125W
.25W
.5W
.66W
M ax .
W o rkin g
Vo ltag e *
15V
25V*
50V*
100V *
150V *
200V *
250V *
M ax .
O ve rloa d
Vo ltag e
1
30V
50V
100V
200V
300V
400V
500V
.040±.004 .020±.002 .014±.004
[1.0±.1]
[.5±.05]
[.35±.1]
100
Ω
- 100K ..063±.008 .031±.006 .018±.006 .012±.008
[1.6±.2]
[.8±.15]
[.45±.15]
[.3±.2]
10
Ω
- 330K
100
Ω
- 100K .079±.006 .050±.006 .018±.006 .014±.008
[2.0±.15] [1.25±.15] [.45±.15]
[.30±.2]
10
Ω
- 1M
100
Ω
-249K
10
Ω
- 1M
.126±.006 .063±.006 .020±.006 .020±.010
[3.2±.15] [1.6±.15] [.50±.15] [.51±.25]
100
Ω
-130K .126±.006 .098±.008 .024±.008 .020±.010
[3.2±.15]
[2.5±.2]
[.61±.2]
[.51±.25]
10
Ω
- 510K
10
Ω
- 1M
10
Ω
- 1M
.165±.008 .118±.008 .028±.006 .030±.016
[4.2±.2]
[3.0±.2]
[.7±.15]
[.76±.4]
*Maximum working voltage determined by E= PR, E should not exceed value listed. Increased voltage ratings available.
1
Extended range available, consult factory.
TYPICAL PERFORMANCE CHARACTERISTICS
Requi rements
Short Time Over Load
Resistance to Soldering Heat
High Temperature Exposure
Thermal Shock
Moisture Resistance
Load Life (1000 hours)
Extended Life (10,000 hrs)
Solderability
Shelf Life
Characteri stics (5-25ppm)* Test Method
±0.05% (± 0.1% Opt.B)
± 0.05%
± 0.1%
± 0.1%
± 0.2%
± 0.1% (±0.2% Opt.B)
± 0.25% (±0.4% Opt.B)
95% (Min.)
100 ppm/year (Max.)
Rated W x 2.5, 5 seconds at 25°C
(not to exceed Max Overload Voltage)
260 ± 5°C, 3 seconds
100 hours @ +125° C
-55°C to +125°C, 0.5 hours, 5 cycles
Mil-STD-202 M.103 95% RH 1000 hrs
Rated W per Mil-PRF-55342 4.8.11.1
Rated W per Mil-PRF-55342 4.8.11.1
MIL-Std-202, Method 208
Room Temp. & Humidity, No-Load
Alumina
Substrate
Inner Electrode
Nickel Barrier
Solder Plating
CONSTRUCTION
Environmental Seal
Metal film resistor
element
Marking avail.
(specify Opt.A)
Dielectric Withstanding Voltage 250V (100V 0402 & 0603) 60 Seconds, terminal to ceramic
*The typical
R level of chips with 50ppm TCR is double that of chips with 5 to 25ppm
DERATING CURVE
Resistors may be operated up to full rated power with consideration of
mounting density, pad geometry, PCB material, and ambient temperature.
P/N DESIGNATION:
BLU1206
RCD Type
Option Codes: P, M, ER, B, A
(leave blank if standard)
4-Digit Resistance Code: 3 signif. digits &
multiplier (10R0=10Ω, 1000=100Ω, 1001=1KΩ)
Tolerance Code: F=1%, D=0.5%, C=0.25%,
B=0.1%, A=0.05% Q=0.02%, T=0.01%
Packaging: ‘B’ Bulk, ‘T’ Tape & Reel
TC: 101=100ppm, 50=50ppm, 25=25ppm, 10=10ppm, 5=5ppm
1002
-
B
T
25
% OF RATED POWER
120
100
80
60
40
20
0
30
40
50
60
70
80
90
100
110
120
130
140
150
AMBIENT TEMPERATURE (°C)
RCD Components Inc.,
520 E. Industrial Park Dr., Manchester, NH USA 03109
Tel: (603) 669-0054 Fax:(603) 669-5455 E-mail: rcdcompinc@aol.com
www.rcd-comp.com
FA013 Specifications subject to change without notice
